Specifications: Audio Specifications; DTS / Dolby Digital
Bandwidth: 18Gbps
Max Distance: 14 m / 45 ft
Video Revision: HDMI 2.0
Wide Screen Supported: Yes
Plug Type: USB Micro-B
Power Consumption (In Watts): <2.5
Power Source: Not Included (not required for standard applications)
Specifications: Audio Specifications: 7.1 surround Sound
Max Distance: 35 m / 115 ft
Maximum Cable Length: 114.8 ft [35 m]
Maximum Digital Resolutions: 1920 x 1080 at 60Hz
Supported Resolutions: 1920 x 1080, 1680 x 1050, 1600 x 900, 1440 x 900, 1360 x 768, 1280 x 800, 1280 x 768, 1280 × 720
Wide Screen Supported: Yes
System and Cable Requirements:
The HDMI cable connected to your video source must be longer or equal to the length of the cable connected to your display.
The maximum supported video source cable length is 82 ft. (25m).
The maximum supported display cable length is 33 ft. (10m).
LED Indicators:
1 - power LED (blue)
1 - video source LED (blue)
Specifications: Standards and Certifications:
HDCP 1.1
DVI 1.0
CE
FCC
RoHS2
Signal Input/Output:
Input video signal: 0.5 – 1.0 V p-p
Input DDC signal: 5 V p-p (TTL)
Maximum single-link range: 1920 x 1200, 1080p
Output video: HDMI 1.3, HDCP 1.1, DVI 1.0
Frequency: 1.65 Gbps / 165 MHz
Video Resolutions:
VGA: 640 x 480, 800 x 600, 1024 x 768, 1920 x 1200
DTV/HDTV: 480i/480p/576i/576p/720p/1080i/ 1080p
Specifications: Maximum Pixel Clock: 2 x 165 MHz
Input Video Signal: 1.2V p-p
Input DDC Signal: 5V p-p
Video Connectors: (2) DVI-I 29-pin, female (digital only)
Power Supply: 5V DC
Power Consumption: 5W (max.)
