Specifications: Network Technology: 1000Base-TX, 1000Base-T
Power Description Plug/Connector Type: Terminal Block (3 Wire), Type N
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 1
Total Number of Expansion Slots: 1.0
Network (RJ-45): Yes
Number of PoE (RJ-45) Ports: 1
Total Number of Ports: 1
Media Type Supported: Twisted Pair
Fiber Mode Supported: Optical Fiber, Single-mode, Multi-mode
Weight (Approximate) 2.80 oz
Height 1.9", Width 1.4", Depth 2.3"
Environmental Compliance: Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate):
5.40 oz
Miscellaneous
Package Contents...
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate):
5.40 oz
Miscellaneous
P...
Specifications: Safety
IEC 60950-1, EN 60950-1, CB Certificate/Report, UL/CSA 60950-1
EMC
CC / ICES-003 Emission (USA/Canada)
CRISP 22 Emission (International)
EN61000-4-2 Electrostatic Discharge
EN61000-4-3 Radiated RFI Immunity
EN61000-4-4 Electrical Fast Transients level 4
EN61000-4-5 Electrical Surge Level
EN61000-4-6 RF Conducted
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
Specifications: Dimensions: 3.80" x 1.20" x 0.90"
Output Interface:
3 x USB-A 3.0 Ports
1 x Gigabit Ethernet Port
Input Interface: 1 x USB-A 3.0 Connector
Chipset: RTL8153
Supported Systems: Windows (XP / Vista / 7 / 8 / 8.1 / 10), Mac OS X (10.5-10.11), Linux OS and Chrome OS
Package Contents:
USB 3.0 3-Port Hub & Gigabit Ethernet Adapter UE330
User Guide
Specifications: Interface:
PoE (Power + Data) Input Port: 1 x RJ-45 STP
Data” Output Port: 1 x RJ-45 STP
DC Out Plug Connector: 1
LED Indicator System: PoE In x 1 (Green)
Network Cable:
10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
100Base-TX: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
1000Base-T: 2-Pair UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
EIA / TIA-568 100-ohm STP (100m)
Data Rate: 10/100/1000 Mbps (varies on Ethernet device attached)
DIP Switch: 12V DC / 24V DC output voltage
Power Input: 802.3at PoE+ 52 ~ 56V DC
PoE Standard: IEEE 802.3at High Power over Ethernet
Number of clients device can be powered: 1
Power Output:
12V DC, 2A max
24V DC, 1A max
Standards Compliance:
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3at...
Specifications: Interface: Input Port:
1 x RJ-45 STP
PoE (Data + Power) In
Output Port
1 x RJ-45 STP
Data Out
DC Socket
DC Out
DIP-Switch
12V DC / 19V DC / 24V DC output voltage
LED Indicator:
System: Power x 1 (Green)
Network Cable:
Ultra PoE (60W): 10/100/1000Base-T: 4-Pair UTP Cat. 5e, 6 up to 100m (328 ft.)
802.3af/at PoE (15W / 30W): 10/100/1000Base-T: 2-Pair UTP Cat. 3, 5, 5e, 6 up to 100m (328 ft.)
Data Rate: 10/100/1000 Mbps
Power Requirements: 52 ~ 56V DC
Power Consumption: 50 watts (maximum)
Operating Temperature: 0 ~ 50 degrees C
Storage Temperature: -10 ~ 70 degrees C
Humidity: 5 ~ 95% (Non-condensing)
PoE Standard: IEEE 802.3at Power over Ethernet Plus
Power Output: DC 12V / 19V / 24V by DIP switch control
DC Plug connectors (Diameter):
2 external female plug cables:
5.5 / 2.5mm to 5.5 / 2.5mm
5.5 ...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
Twisted Pair
Optical Fiber
Fiber Mode Supported:
Multi-mode
Fiber Optic Cable Wavelength:
0 mil
Maximum Distance Supported:
0.55 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
Color Family:
Black
Product C...
Specifications: Interfaces:
PoE IN:1 x 10/100/1000BASE-T Ethernet with IEEE 802.3at PoE "Data + DC power" in auto MDI/MDI-X, auto-negotiation RJ45 connector
PoE OUT: 2 x 10/100/1000BASE-T Ethernet with IEEE 802.3at/802.3af PoE "Data + DC power" out auto MDI/MDI-X, auto-negotiation RJ45 connector
Power over Ethernet
PoE Standard:
"PoE In" Port: IEEE 802.3at Power over Ethernet Plus end-span/mid-span PD class 4 PD
Per "PoE Out" Port:
IEEE 802.3at Power over Ethernet Plus end-span PSE
IEEE 802.3af Power over Ethernet end-span PSE
PoE Power Supply Type: End-span (Type A)
PoE Power:
"PoE In" Port: 52 - 56V DC, max. 30.8 watts
Per "PoE Out" Port: 44 - 55V DC, max. 25 watts
Power Pin Assignment:
"PoE In" Port: 1/2 (+), 3/6 (-); 4/5 (+), 7/8 (-)
Per "PoE Out" Port: 1/2 (+), 3/6 (-)
Data Rate: 10/100/1000Mbps
MAC Address Table: 2K
Data Bu...
Specifications: PoE Standard: IEEE 802.3af (Power over Ethernet)
IEEE 802.3at (High Power over Ethernet)
PoE Power Supply Type: Mid-Span / Type B
PoE Power Output: 52V DC, 510 mA, Max. 26 watts
Power Pin Assignment: 4/5 (+), 7/8 (-)
Maximum Distance: 4 units, daisy-chain installation with 500m support
Data Rate: 10/100/1000 Mbps
Switch Architecture: Store-and-Forward
Maximum Frame Size: 1552 Bytes
Flow Control:
Back pressure for half-duplex
IEEE 802.3x pause frame for full-duplex
LED Indicators:
1 x PoE IN (Green)
1 x LAN Data (Green)
1 x PoE OUT (Green)
Power Requirements: IEEE 802.3at compliant with voltage within 52V-56V DC
Power Consumption: 3.2 watts (system maximum)
Specifications: Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
Device Interface:
1 x Gigabit PoE/PoE+ in port
1 x Gigabit PoE/PoE+ out port
1 x Power port (optional power adapter is not included)
LED indicators
Installation mounting points
Data Transfer Rate:
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit: 2000 Mbps (full duplex)
Power:
Powered by PoE/PoE+ Device
Consumption: 2 Watts (max.)
