Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
Specification: Ports In:
1 x HDMI Female
Ports Out:
Video Output: 1 x HDMI Female
Audio Output: 1 x TOSLINK (Optical) / 1 x RCA (Coaxial) / 2 x RCA (Stereo)
1 x DC Jack
Console Connectors (Flash ROM Upgrade): 1 x 4-conductor 3.5 mm Jack
1 x (Green) Power On LED
Switches
Mode Selection: Audio Channel - 1 x Slide Switch / HDMI Audio On/Off - 1 x Slide Switch
F/W Upgrade: 1 x semi-recessed pushbutton
Power: 5.3 VDc/150 mA
Power Consumption: 0.8 W - 3 BTU / hr
Dimension: 7.9" x 3.2" x 1"
Weight: 1 lbs.
Feature: Repeats HDMI input signal up to 15 meters
Extracts HDMI audio signal and outputs as additional audio source
Supports optical / coaxial digital audio and analog stereo audio
HDMI and HDCP compatible
Super Video Quality - up to 1920x1080 (1080p)
Firmware upgradable
CH2/CH5...
Specification: Compliant with HDCP 2.2
Transmission Distance:
4K@60Hz: Up to 70m via Cat6/7 cable
4K@60Hz: Up to 40m via Cat5 cable
Full frequency IR signal from 20KHz to 60KHz
RS-232: 3-pin: GND-RxD-TxD, follow RS-232 Levels, Support up to 115200 baud rates
Network cable: UTP/STP CAT5e/6/6a/7
Resolution Support: Up to 3840x2160 @60Hz, 2160p / 1080p / 1080i / 720p / 480p
