Network Interface: USER INTERFACE:
Indicator LEDs: Outputs, inputs, communication link and power
Controls: EDID setup button, 12 setup DIP switches
1 RS-232: On a Mini–USB female connector for firmware upgrade
S-Video: VIDEO:
Max. Data Rate: 10.2Gbps (3.4Gbps per graphic channel)
Max. Resolution: Up to 4K@60Hz (4:2:0) 24bpp
Standards Compliance: Supports HDCP 1.4 and HDBaseT 1.0
HDMI Support: Deep Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0
Resolution Support: Up to 1920 x 1200@35 m (Cat 5e/6) / 40 m (Cat 6a); 1080p@60 m (Cat 5e/6) / 70 m (Cat 6a)
Power Supply: VE601R
Connectors: 1 x DC Jack with locking
Consumption: 5 VDC, 4.23 W
VE601T
Connectors: 1 x DC Jack with locking
Consumption: 5 VDC, 1.85 W
Feature: The VE601 DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to me...
Resolution Support: Maximum Digital Resolutions: 3840 x 2160 (4K) @ 60 Hz
Supported Resolutions:
3840 x 2160 (4K) 60 Hz
2560 x 1600 60 Hz
1920 x 1200 60 Hz
1920 x 1080 (1080p) 60 Hz
1280 x 720 (720p) 60 Hz
* Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Audio: 7.1 Surround Sound
HDMI: Connector A: 1 x HDMI (19-pin) Female
Connector B: 1 x HDMI (19-pin) Female
