Ports Spec: 2 x display / video - DisplayPort - 20 pin DisplayPort
1 x display / video - HDMI - 19 pin HDMI Type A
1 x USB-C
3 x USB 3.1 Gen 1 - 9 pin USB Type A
2 x USB-C 3.1 Gen 2
1 x network - Ethernet 1000 - RJ-45
Ports Spec: 1 x USB-C 3.2 Gen 2
1 x USB-A 3.2 Gen 1 with PowerShare
2 x DisplayPort 1.4
1 x HDMI 2.0
1 x USB-C Multifunction DisplayPort
2 x USB-A 3.2 Gen 1 port
1 x Gigabit Ethernet RJ45
1 x Power In
2 x Thunderbolt 4
Compatibility: Designed For
Inspiron 14 7460, 15 Gaming 7567; Latitude 13 3379 2-in-1, 13 3380, 3189, 3480, 3580, 5280, 5285 2-in-1, 5289 2-In-1, 5480, 5580, 7280, 7480; Vostro 14 5468, 15 3568, 15 5568; XPS 13 9365 2-in-1
System Requirements
OS Required
Windows 7, 8, 8.1, 10 (32/64bit) or later
System Requirement (Recommended)
PC's equipped with USB3.0 or USB-C port
DisplayLink Driver installation
Refer user guide for details of system specs requirement
Ports Spec: 1 x USB Type C
1 x display / video - HDMI
2 x display / video - DisplayPort
1 x USB host
3 x SuperSpeed USB 3.0
1 x SuperSpeed USB 3.0 with PowerShare
1 x USB Type C with PowerShare
1 x headphones / speakers
Compatibility: OS Required: Microsoft Windows7, Microsoft Windows8; 8.1, 10, Ubuntu 14.04 SP1 (PRTS), RedHat Enterprise Linux v7.2(PRTS)
Ports Spec: 2 x USB 2.0 - 4 pin USB Type A 3 x SuperSpeed USB 3.0 - 9 pin USB Type A 1 x display / video - HDMI - 19 pin HDMI Type A 1 x display / video - mini DisplayPort 1 x network - Ethernet 1000 - RJ- 45 1 x headset / headphones / microphone - output - mini-phone 3.5 mm 1 x audio - output - mini-phone 3.5 mm 1 x video - VGA - 15 pin D-Sub (DB-15)
Compatibility: OS Required
Ubuntu Linux 14.04 SP1, Microsoft Windows 7 / 8 / 8.1 / 10, Red Hat Enterprise Linux 7.2
Designed For
Latitude 7280, 7380, 7480, 7285, 5480, 5580, 5290 2-in-1, 7390 2-in-1, 7290, 7390, 7490, 5491, 5591
Precision 3520, 7520, 7720, 5520, 3530, 5530, 7530, 7730, 5530 2-in-1
XPS 9560, 9360, 9365, 9360, 9575, 9370, 9570
Ports Spec: 2 x USB 2.0 - 4 pin USB Type A
3 x SuperSpeed USB 3.0 - 9 pin USB Type A
1 x display / video - HDMI - 19 pin HDMI Type A
1 x display / video - DisplayPort - 20 pin DisplayPort
1 x network - RJ-45
1 x headset - output - mini-phone 3.5 mm
1 x speakers - output - mini-phone 3.5 mm
1 x video - VGA - 15 pin D-Sub (DB-15)
1 x Thunderbolt 3 - Thunderbolt - 24 pin USB-C
1 x display / video - DisplayPort - Mini DisplayPort
Features: 2x USB 3.0, 3x USB 2.0, 1x VGA, 2x DVI-D, 2x Display Port 1x Serial, 2 x PS/2 Connectors, 1 x Parallel Connector, 1x mouse 1x Keyboard, RJ-45 Ethernet Port, Microphone in, 3.5mm Headphone Jack Security Cable Slot, Lock/Unlock Switch, easy removal with eject button 240W AC Adapter, See Full
Compatibility: This product is compatible with the following systems:
XPS 13 (9350)
XPS 15 (9550)
XPS 12 (9250)
Precision 15 7000 Series (7510)
Precision 17 7000 Series (7710)
Precision 15 3000 Series (3510)
Precision 15 5000 Series (5510)
Latitude E5570
Latitude 7275
Latitude 7370
XPS 13 (9360)
Latitude 5480
Latitude 5580
XPS 9365
XPS 9560
Precision 5520
Latitude 7280
Precision 3520
Latitude 7480
Thunderbolt 3: Yes
Ports Spec: Supports 3 displays
Two USB 2.0 ports
Three USB 3.0 ports
Thunderbolt 3 (USB-C) port
Speaker output (rear)
Combo audio (front)
Gigabit Ethernet
Kensington Lock Slot
7.4 mm DC-IN Power Input
Compatibility: Latitude E4200
Latitude E4300
Latitude E4310
Latitude E5400
Latitude E5410
Latitude E5420
Latitude E5430
Latitude E5440
Latitude E5500
Latitude E5510
Latitude E5520
Latitude E5530
Latitude E5540
Latitude E6220
Latitude E6230
Latitude E6320
Latitude E6330
Latitude E6400
Latitude E6400 ATG
Latitude E6400 XFR
Latitude E6410
Latitude E6410 ATG
Latitude E6420
Latitude E6420 ATG
Latitude E6420 XFR
Latitude E6430
Latitude E6430 ATG
Latitude E6430s
Latitude E6440
Latitude E6500
Latitude E6510
Latitude E6520
Latitude E6530
Latitude E6540
Latitude E7240
Latitude E7440
Ports Spec: 1 x display / video - DisplayPort
1 x display / video - DVI-Digital - 18 pin digital DVI (Single-Link)
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
2 x SuperSpeed USB 3.0 - 9 pin USB Type A
1 x eSATA / USB 2.0 - 11 pin USB/eSATA
3 x USB 2.0 - 4 pin USB Type A
1 x netwo...
Compatibility: Compatibility: Dell Notebooks/Tablet PCs: Inspiron 13 5000 Series (5368), Inspiron 13 7000 Series (7368), Inspiron 15 5000 Series (5568), Inspiron 15 7000 Series (7569), Inspiron 17 7000 Series (7778), Latitude 11 (5175), Latitude 11 (5179), Latitude 7275, Latitude 7370, Venue 10 Pro (5056), Venue 8 Pro (5855), XPS 12 (9250), XPS 13 (9350).
Ports Spec: 5 x 4-pin Type A USB 2.0 USB
1 x RJ-45 Network
1 x 15-pin HD-15 VGA
1 x 24-pin DVI-D Digital Video
1 x 20-pin Display Port Digital Video
1 x eSATA
Audio
Compatibility: This docking station is compatible with the following systems:
Latitude E5510, E5520, E6220, E6320
Precision M4400, M4500, M4700, M6400, M6500, M6600, M6700
Ports Spec: 1 x serial - RS-232 - 9 pin D-Sub (DB-9)
1 x parallel - 25 pin D-Sub (DB-25)
1 x keyboard - generic - 6 pin mini-DIN (PS/2 style)
2 x USB - 4 pin USB Type A
1 x network - RJ-45
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
2 x display / video - DVI-Digital - 24 pin digital DVI
2 x display / video - 20 pin DisplayPort
1 x mouse - generic - 6 pin mini-DIN (PS/2 style)
Audio
