Type: DisplayPort to Dual Link DVI-D Active Adapter
Color: Black
Cable Length: 7 inch
Specifications: Connector Types: 1 x 20 pin DisplayPort Male, 1 x 19 pin DVI-D Female
Compatibility: TV’s, monitors, and projectors with a DVI output
DisplayPort Receiver Capability:
Supports 1, 2, and 4 lanes at both 1.62Gb/s and 2.7Gb/s data rates
Built-in automatic receiver equalization
Supports both full link training and no link training operation
Video input formats: RGB up to 12 bpc, YCbCr4:4:4 -4:2:2 up to 12 bpc
Supports reduced blanking or reduced refresh rate timing modes
Supports DisplayPort Spread Spectrum Clocking
DVI Transmitter Capability:
Fully TMDS/iTMDS compliant, while fully interoperable in the DVI 1.0 environment
Video output formats: RGB up to 12 bpc, YCbCr4:4:4 -4:2:2 up to 12 bpc
Supports Dual-Link iTMDS interface for increased ...
Specifications: Connect a HDMI monitor to a computer with a Displayport output
Displayport (Male) to HDMI (Female); fully-molded
Supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p
The P136-000-1 supports transmission of an audio signal as long as it is supported by the Displayport source. Check the documentation for your Displayport source for compatibility.
Supports DTS-HD, Dolby True HD and 7.1 Channel Surround Sound Audio
The P136-000-1 is a passive adapter and requires that the connected computer has a DP++ ( Displayport ++ ) port, which allows HDMI and DVI signals to be passed through; check the documentation for your Displayport source for compatibility.
HDCP-compliant
System Requirements
Computer with a Displayport output
Dis...
Specifications: Connector A DISPLAYPORT (MALE)
Connector B DVI-D DUAL-LINK (FEMALE) (WIRED TO DVI-D SINGLE-LINK)
Connector C HD15 (FEMALE)
Connector D HDMI (FEMALE)
Operating Systems Supported: Microsoft Windows 8 (32 / 64bit)
Windows 7 (32 / 64bit)
Windows Vista (32 / 64bit)
Windows XP (32 / 64bit)
Windows Server 2012 (32 / 64bit)
Windows Server 2003 / 2008 (32 / 64bit) and Linux
