Changer Type: DisplayPort Male to HDMI Female + VGA Female
Color: Black
Specifications: This DisplayPort 1.2 to HDMI/VGA adapter allows you to transmit signals from a DisplayPort device to a high definition HDMI or VGA display.
Gold-plated connector provides superior transmission, high reliability and durability.
DisplayPort connector with latches keeps cable securely plugged in.
All relevant materials are complied with RoHS directive.
Specifications: Maximum Analog Resolution: 1920x1200
Adapter Style: Adapter
Audio: No
Converter Type: Active
Enclosure Type: Plastic
Humidity: 10%-85% RH
Operating Temperature: 0 Degree C to 45 Degree C
Storage Temperature: -10 Degree C to 70 Degree C
Specifications: Audio Specifications: 5.1 Surround Sound (Video source and destination dependant)
Maximum Analog Resolutions : 1920x1200/1080p
Maximum Digital Resolutions: 1920x1200/1080p
Wide Screen Supported: Yes
Specifications: HDMI: Yes
Network: Yes
Modem: No
Composite Video: No
S-Video: No
VGA: Yes
Audio: Yes
USB: Yes
Serial Port: No
Number of Network (RJ-45) Ports: 1
Number of USB Ports: 1
Specifications: Connector A DISPLAYPORT (MALE)
Connector B DVI-D DUAL-LINK (FEMALE) (WIRED TO DVI-D SINGLE-LINK)
Connector C HD15 (FEMALE)
Connector D HDMI (FEMALE)
Changer Type: Mini DisplayPort to VGA Active Adapter
Color: Black
Specifications: Mini DP to VGA adapter connects a VGA monitor to the Mini DisplayPort or Thunderbolt 1/2 output on your laptop or computer.
Continue using your current VGA display without the expense of a new Mini DP monitor
Delivers high-definition picture quality at resolutions up to 1920 x 1200, including 1080p
Active adapter converts single- and dual-mode DP++ output for viewing on VGA display
Compact unit fits easily into briefcase or laptop bag for instant use anywhere
Plug-and-play operation with no software required for easy, immediate installation
Specifications: Compatible with DisplayPort 1.1 and 1.2 specifications
Supports VGA output resolutions up to 1920x1200
Allows you to connect to a VGA display for a larger work area.
Adapter is 9.25 in length (Cable length is 5.8 in)
Mini Displayport to VGA Female
Chipset: PS8617
Type: MINI DISPLAYPORT TO VGA ADAPTER CONVERTER CABLE ,Mini DisplayPort DP Male to VGA Female Adapter Cable Converter for Apple iMac, Mac Mini, MacBook Air 11" 13", Macbook Pro 13" 15" 17"
Specifications: Chipset ID: STDP4320
Output Signal: DisplayPort
Ports: 3
Maximum Digital Resolutions: Up to 4K
Wide Screen Supported: Yes
OS Compatibility: Windows 10 (32/64), Windows 8/8.1 (32/64), Windows 7(32/64)
Center Tip Polarity: Positive
Input Current: 0.5 A
Input Voltage: 110V-240V AC
Output Current: 3A
Output Voltage: 5 DC
Plug Type: N
Power Consumption (In Watts): 15
Power Source: AC Adapter Included
Operating Temperature: 0 to 45 degree C (32 to 113 degree F)
Storage Temperature: -20 to 70 degree C (-4 to 158 degree F)
Enclosure Type: Plastic
Connector A: 1 x DisplayPort (20 pin) Latching Male
Specifications: Performance Grade: Good
Resolution: Supports PC resolutions up to 1920x1200(WUXGA-R), 60Hz, 8bpc: 154MHz;1920x1080P, 60Hz, 10bpc: 144MHz
Versions Supported: DisplayPort 1.1 input and VGA output
Power requirements: Powered from DisplayPort source
Construction: The DP to VGA adapter uses an integrated chip to provide an active digital to analog conversion
Weight Lbs: 0.2
RoHS Compliant: Yes
Specifications: Converter Type: MST Hub
Ports: 3
Audio: Yes
Connectors:
-Connector A: 1 x Mini-DisplayPort (20 pin) Male
-Connector B: 3 x DisplayPort (20 pin) Latching Female
Wide Screen Supported: Yes
OS Compatibility: Windows 8 (32/64), Windows 7(32/64)
Color: Black
Enclosure Type: Plastic
Maximum Digital Resolution: 2560 x 1600
Type: Conference Table Connectivity Box for A/V - 4K
Color: Black
Specifications: Input Voltage: 100 ~ 240 AC
Output Current: 2A
Output Voltage: 12 DC
Plug Type: N
Power Consumption (In Watts): 24W
Power Source: AC Adapter Included
Aspect Ratio: Wide (16:9)
Maximum Analog Resolutions: 1920 x 1200 60Hz
Maximum Cable Length: 50 ft [15.2 m]
Maximum Digital Resolutions: 3840x2160 (4K) 30Hz
Supported Resolutions:
3840x2160 (4K) 30Hz (HDMI and DP Inputs Only)
2560x1600 60Hz (HDMI and DP Inputs Only)
1920x1200 60Hz (Maximum VGA Input)
1920x1080 (1080p) 60Hz
1280x720 (720p) 60Hz
**Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Video Revision: HDMI 1.4 / DisplayPort: 1.2
Wide Screen Supported: Yes
Note:
VGA (Input) to HDMI (Output) - HDMI Output Port is Active
DisplayPort (Input) to HDMI (Output) - ...
