Specifications: Screen: <= 34.00"
Lift: 13.00" (33.00 cm)
Tilt Range: 70 degrees backward, 5 degrees forward
Pan: 360 degress
Rotation: 360 degrees
VESA: MIS-D
Mounting Options: Desk Clamp attaches to surface edge 0.40" to 2.40" (10.00 to 60.00 mm) thick; Grommet Mount attaches through surface holes 0.31" to 2.00" (8.00 to 50.00 mm) wide and up to 2.25" (57.00 mm) thick
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100.00 x 100.00 mm & 75.00 x 75.00 mm)
Weight Capacity: 7.00 to 25.00 lbs. (3.20 to 11.30 kg). With monitors greater than 20.00 lbs. (9.10 kg) in weight, the vertical range of motion may be reduced up to 4.50" (11.00 cm) for a total height range of 8.50" (22.00 cm)
Note: If installed on WorkFit-T or WorkFit-TL, maximum allowable monitor weight is reduced to 14.00 l...
Specifications: Works with a wide variety of power strips and surge protectors
Secures the power strip firmly against the cart’s center column to minimize the strip’s profile and space usage
Keeps cords organized
Strong, steel construction
Simple installation
Specifications: Display size is dependent on overall configuration of the DS100 Stand; observe balance requirements to prevent tipping
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Attaches to DS100 Pole only; cannot attach to DS100 Crossbar
Specifications: OSHPD Pre-approval Number OPA-0620
Fasteners for attaching to wall not included. Fasteners may be purchased from Ergotron: part number 97-531 for metal or wood studs; part number 90-011 for hollow walls
Separately-order brackets required to attach Ergotron components: part number 97-091 for LX & MX Arms, Neo-Flex Wall Mounts, 400, 200 and 100 Series Arms and Pivots, and Universal CPU Holder; part number 60-156 for Medium and Small CPU Holders
Dimensions: 26" x 5" x .87" (660 x 127 x 22 mm)
Shipping Weight: 4 lbs (1.8 kg)
Specifications: LCD Size: < 24"
Weight Capacity: 6–16 lbs (2.7–7.2 kg)
Lift: 5", 13 cm
Tilt: 30°
Pan: 270°
Rotation: 90° P/L
VESA: MIS-D
Description: Neo-Flex LCD Desk Stand (black & silver)
Meets UL Specification 1678 Tip Test when loaded with all weights of LCDs
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Specifications: LCD Size: Up to 24"(Up to 61 cm)
Weight Capacity: Up to 23 lbs(Up to 10.35 kg)
Tilt: 180°
Pan: 180°
Rotation: 360° P/L
VESA: MIS-D
DS100 Dual-Monitor Desk Stand, Vertical (black)
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Shipping Dimensions: 28" x 16" x 7.5" (711 x 406 x 191 mm)
Shipping Weight: 16 lbs (7.3 kg)
Specifications: Colour: black
Includes 200 Wall Mount Pivot, wall mount bracket, 1 extension, VESA mounting screws
Extends up to 14.8" (37.6 cm) from the wall and retracts to within 5.8" (14.8 cm), excluding depth of monitor
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Weight Capacity: 25 lbs (11.3 kg)
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Durable, easy-to-clean powder-coated painted steel exterior
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud
Specifications: Includes Includes: 10" and 34" Wall Tracks with two black track covers, LX Wall Mount LCD Arm, LX Keyboard Arm, wrist rest, mouse pad, mouse holder, Small CPU Holder, two 10" Cable Channels, mounting kits for hollow-wall and wall-stud installation
Quality Tested: 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment
Polished aluminum construction offers greater durability and enhanced aesthetics
Snap-fit cap secures interface of arms to extensions for greater stability
Weight Capacity: display = 7-25 lbs (3.2-11.3 kg); keyboard = 5 lbs (2.2 kg); CPU = 50 lbs (22 kg). With monitors greater than 20 lbs (9.1 kg) in weight, the vertical range of motion may be reduced up to 4.5" (11 cm) for a total height range of 8.5" (22 cm)
Mounting Standards: VESA FDMI MIS...
Specifications: Device Support: Flat Panel Display / Keyboard
Maximum Screen Size Support: 24"
Color: White
VESA Mount Compatible: Yes
VESA Mount Standard: 75 x 75 /100 x 100
Material: Steel
Specifications: Certifications & Standards: VESA 100/75
VESA FDMI MIS-D
VESA C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Load Capacity: 35 lb Maximum
Color: Black
Specifications: LCD Size: < 24"
Wt. Capacity: 6–16 lbs, 2.7–7.2 kg
Lift: 5", 13 cm
Tilt: 35°
Pan: 70°
Rotation: 90° P/L
VESA: MIS-D
Description: Neo-Flex Wall Mount Lift (black)
Monitor depth greater than 2" (5 cm) may diminish capacity. Read more
Mounting Standards: VESA FDMI, MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. To increase support, a separately-ordered Wall Track accessory is recommended
Specifications: Wall Track is a low-cost, zero-footprint mounting system that attaches to most vertical surfaces. It accommodates an entire computer workstation.
Separately-ordered brackets are required to attach components to Wall Track (view + Accessories). The height of components can be adjusted by loosening set-screws on these brackets.
Description: 42" Wall Track (aluminum) with cable management channel covers
Dimensions: 42" x 5" x .87" (1067 x 127 x 22 mm)
OSHPD Pre-approval Number OPA-0620
Fasteners for attaching to wall not included. Fasteners may be purchased from Ergotron: part number 97-531 for metal or wood studs; part number 90-011 for hollow walls
Separately-order brackets required to attach Ergotron components: part number 97-091 for LX & MX Arms, Neo-Flex Wall Mounts, 400, 200 and 100 Series Arms and Pivot...
Specifications: LCD Size: <= 24"
Lift: 13"(33 cm)
Tilt : 85°
Pan: 360°
Rotation: 360° P/L
VESA: MIS-D
Versatile: Use with a notebook and LCD or with two LCDs
Weight Capacity: Maximum individual LCD weight = 7 to 20 lbs (3.1 to 9.1 kg); notebook weight range = 2.5–12 lbs (1.1–5.4 kg); maximum combined weight = 40 lbs (18.1 kg). Monitor depth may affect weight capacity
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Shipping Dimensions: 19.25" x 15.25" x 9" (487 x 387 x 229 mm)
Shipping Weight: 15.75 lbs (7.18 kg)
Specifications: Description: Tall-User Kit for WorkFit Dual
Includes two (2) single monitor pivots, two (2) riser brackets, installation hardware
* Maximum outside width of display is 21.25" (54 cm) when displays are 2" (5 cm) thick. This is typically the horizontal dimension of a 22" diagonal screen-size monitor. Actual allowable width of displays will vary slightly depending on display thickness
** Weight Capacity: 6 - 14 lbs. (2.7 - 6.3kg) per display, 12 - 28 lbs. (5.5 - 12.7kg) combined
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Specifications: Device Supported: Flat Panel Display
Maximum Load Capacity: 25.00 lb
Maximum Screen Size Supported: 42"
Color: Polished Aluminum
VESA Mount Compatible: Yes
VESA Mount Standard: 75 x 75, 100 x 100, 200 x 100, 200 x 200
Height: 20.0"
Depth: 33.0"
Weight (Approximate): 11.00 lb
Specifications: Glide Wall Mount will be hidden behind display in most cases when used with screen size of 46" or greater; when used with screens smaller than 46", the mount may be visible
Mounting holes must fit within spacing range below:
Horizontal = 100 mm (min.) to 400 mm (max.)
Vertical = 100 mm (min.) to 400 mm (max.)
Includes low-profile lift module, mounting template, tilt brackets, installation and mounting hardware, cable management hardware
Specifications: Compatibility: <=24" LCD
Weight Capacity: 5-30 lbs(2.3-13.6 kg)
Lift: 9"(22.9 cm)
Tilt: 10°
VESA: MIS-D
Additional Information:
Negative-tilt keyboard tray is adjustable 0° to -10°
Maximum Monitor Weight = 25 lbs (11.3 kg)
Monitor thickness greater than 3" (7.6 cm) may decrease capacity
Integrated Cable Management System can be Configured on Either Side
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Package Contents:
StyleView 60-593-195 Vertical Mount Lift
Mouse Pad
Wrist Rest
Mouse Pouch
Type: WorkFit C-Mod, Single Display Sit-Stand Workstation
Specifications: LCD Size: = 22"
Capacity: 5–18 lbs/2.3–8.1 kg
Lift: 25"/63 cm
Tilt: 25°
Rotation: 360° P/L
VESA: MIS-D
Includes cart, LCD pivot, integrated worksurface, keyboard tray with left/right mouse tray, wrist rest, mouse holder, cable storage box, CPU holder, four dual casters (two locking)
Lift Range: LCD/keyboard/worksurface adjusts 20" (51 cm) in tandem; LCD adjusts 5" (13 cm) independently; maximum LCD height adjustment = 25" (63 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Constant Force (CF) lift-and-pivot motion technology
CPUs attach safely to rear of cart with CPU Holder. Accommodates CPUs from 12"H x 3"D to 18"H x 8.5"D (30 x 8 cm to 46 x 22 cm)
CPU Holder capacity = 40 lbs (18 kg)
Ergonomic negative-t...
Specifications: Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
LCD Size: 30"
Capacity: 31 lbs
Rotation: 360° P/L
Attaches to Crossbar and Crossbar Extenders
Cannot be used as the Center Display Bracket when three displays are attached to Crossbar
Install displays with 4°-angle off-set : position them upward, inward or downward for optimized viewing conditions
Specifications: LCD Size: < 24"
Wt. Capacity: < 25 lbs, 11.3 kg
Tilt: 180°
Rotation: 360° P/L
VESA: MIS-D
Description: Neo-Flex Dual Monitor Wall Mount
Includes two (2) 100 Series Single Pivots, 26" Wall Track, two (2) Track Mount Bracket Kits
Mounting Standards: VESA FDMI, MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Specifications: Description: NF Basket and Handle Kit (grey)
Includes handle, basket, mounting hardware
Compatible with Neo-Flex WorkSpace Carts and WorkFit C-Mod Workstations
Inside dimensions of basket: 5.875"H x 13.25"W x 3.125"D (149 x 337 x 79 mm)
Durable plastic and metal design
Specifications: Glide Wall Mount will be hidden behind display in most cases when used with screen size of 46" or greater; when used with screens smaller than 46", the mount may be visible
Mounting holes must fit within spacing range below:
Horizontal = 200 mm (min.) to 400 mm (max.)
Vertical = 100 mm (min.) to 400 mm (max.)
Includes low-profile lift module, mounting template, tilt brackets, installation and mounting hardware, cable management hardware
