Specifications: Typical Applications:
Install an LCD display in an open frame or floor rack to monitor essential server-room or console information
Mount a touch-screen display for instant on-site operation and control of rack equipment
System Requirements: LCD display with 75 x 75 mm, 100 x 100 mm or 100 x 150 mm VESA plate
Specifications: Color: Silver with black donuts
Max Weight per mount: 26.5 lbs.
Mounting Hole Pattern (mm): 75 x 75; 100 x 100
Screen rotation (portrait/landscape): 360 degrees
Tilt/pan adjustment: Ball joint mechanism allows 20 degrees display adjustment in any direction from the vertical plane
Pole height: 30"
Cable management: Internal / Integrated
Mounting options: Freestanding
Pole diameter: 1.6
Foot print: 16.6" x 12"
