Compatibility: Operating System: Mac OS 10.14 Moajve or later, Windows 10 or later
Thunderbolt 3: Yes
Ports Spec: Thunderbolt Ports:
1 x Thunderbolt 3 (Input)
Power Delivery:
Up to 85W for host laptop
Up to 15W for USB-C ports
Up to 7.5W for USB-A ports
Video Output:
2 x HDMI 2.0 (Up to 4096 x 2160 pixels each)
USB Ports:
2 x USB-A SuperSpeed 5Gbps
2 x USB-C SuperSpeed 10Gbps
Ethernet:
1 x Gigabit Ethernet
Audio:
1 x 3.5mm combo port, 24-bit 192kHz
Media Reader:
1 x SD Card Reader, UHS-II
Lock Management:
1 x Kensington Security Slot
Part Number: 1x USB-C(PD IN,100W), 1x HDMI1 (4K@30Hz), 1x HDMI2 (4K@60Hz), 1x VGA(1080P), 1x Gigabit RJ45, 2xUSB3.0-A(5Gbps), 2 x USB2.0-A(480Mbps), 1x SD Card Slot, 1x TF Card Slot, 1 x Audio/Mic Port
Compatibility: for MacBook, MacBook Pro 2016/2017/2018/2019/2020, iMac/ iMac Pro (21. 5 inch, 27 inch), Google Chromebook Pixel, Huawei MateBook, Huawei MateBook Pro, Dell, Surface Book2, HP, Lenovo, and Samsung S9, S9 Plus, S8, S8 Plus, Note 9, Note 8, Huawei New version phones and many other type-c port of full function
Ports Spec: 2x 4K HDMI, 1x 2K VGA Port, 1000M RJ45 Ethernet Port, Type C PD 3. 0 charging port, 2x USB 3. 0 Ports, 2x USB 2. 0 Ports,3.5mm Audio Jack, and SD & TF card reader
Specifications: Audio: Yes
Chipset ID: STDP4320
Converter Type: MST Hub
Output Signal: HDMI
Ports: 2
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) @60 Hz - 22%
1920 x 1200 @60hz - 30%
2560 x 1440 @60hz - 35%
2560 x 1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30 Hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
