Specifications: Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate) : SATA
Drive Size: 2.5in
Interface USB: 3.1 Gen 2
Number of 2.5 inch bays: 1
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 2TB at 7200 RPM
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s
UASP Support: Yes
Specifications: Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB 3.1 USB Type-A (9 pin; Gen 2; 10 Gbps) Male
Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate): SATA
Drive Size: 2.5in
Interface: USB 3.1 Gen 2
Number of 2.5 inch bays: 1
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 2TB at 7200 RPM
Maximum Data Transfer Rate : 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s
UASP Support: Yes
Specifications: Connector on First End:1 x Type A Male USB 3.0 USB
Connector on Second End:1 x 40-pin IDC Female IDE
1 x 7-pin Male Serial ATA 3.0 SATA
Package Contents: USB 3.0 to SATA / IDE Combo Adapter
USB 3.0 Cable - 2.5 ft.
4-Pin Molex Power Cable
External Power Supply (Input: 100-240V, 50/60Hz, 0.8A Output: 12V, 2A)
Owner's Manual
Backup Software CD
Specifications: Interface: USB 3.0
Support Devices: IDE & SATA I/II/III, SSDs, Hard Drives, CD/DVD/Blu-ray Drives
Drive Size: 2.5" & 3.5" & 5.25"
LED Indicators: 1 x IDE; 1 x SATA; 1 x USB; 1 x Power
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10 (32 or 64 bit)
Mac OS X v10.6 and Up
Linux OS
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
Specifications: Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate): SATA
Drive Size: 2.5in & 3.5in
Interface : USB 3.1 Gen 2
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 6TB
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 1 - Power and Activity
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 110 ~ 240 AC
Output Current: 2.0 A
Output Voltage: 12 DC
Plug Type: M
Power Source: AC Adapter Included
Specifications: System Requirements
Any USB-enabled operating system
Available USB port (USB 3.0 required to achieve USB 3.0 speeds)
2.5 in. SATA drive
UASP-enabled host controller required for UASP performance
Operating Temperature Range: 50 to 122 degree F (10 to 50 degree C)
Storage Temperature Range: 32 to 149 degree F (0 to 65 degree C)
Specifications: Interface: USB 3.0
Support Devices: IDE & SATA I/II/III, SSDs, Hard Drives, CD/DVD/Blu-ray Drives
Drive Size: 2.5" & 3.5" & 5.25"
HDD Capacity: Up to 8TB
Power Supply: Ac Adapter
Material: Plastic
Dimensions: 63.00 x 42.00 x 14.00 mm
USB cable Length: 457.00 mm
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10 (32 or 64 bit)
Mac OS X v10.6 and Up
Linux OS
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
Specifications: The USBPLATE4 4 port USB 2.0 slot plate adapter converts the USB pins on your motherboard into four USB-A female ports, enabling you to add USB connections to the back of your PC.
Backed by Lifetime Warranty, the USBPLATE4 is designed and constructed for maximum durability, to ensure dependable performance.
Please Note: Check your motherboard’s manual for the USB pinout diagram. The USBPLATE wiring scheme is: Red=Power, Green=Signal, White=Signal, Black=Ground
Connector A: 2 x IDC (10 pin, Motherboard Header) Female
Specifications: System Requirements:
Any USB-enabled operating system
Available USB-C port (USB 3.1 required to achieve USB 3.1 speeds)
2.5 in. or 3.5 in. SATA drive
UASP-enabled host controller required for UASP performance
Operating Temperature Range: 50 to 122 degree F (10 to 50 degree C)
Storage Temperature Range: 32 to 149 degree F (0 to 65 degree C)
