Ergotron Monitor Accessories

• Type: Desk Monitor Arm
• Model #: 45-475-026

• Type: Wall Mount Arm
• Specifications: LCD Size: = 24" Weight Capacity: <= 25 lbs(= 11.3 kg) Tilt: 180° Pan: 360° Rotation: 360° P/L VESA: MIS-D Includes 200 wall mount pivot, wall mount bracket, 2 extensions, VESA mounting screws If mounting a laptop, also order the LX Notebook Tray (50-193-200) Weight Capacity: 25 lbs (11.3 kg) Monitor depth greater than 3" (7.5 cm) may diminish capacity Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm) Extends up to 23.8" (60.5 cm) from the wall and retracts to within 5.8" (14.8 cm), excluding depth of monitor Durable, easy-to-clean powder-coated painted steel exterior Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud
• Parts: 5 years limited
• Labor: 5 years limited
• Model #: 45-234-200

• Type: Keyboard Tray
• Specifications: Device Supported: Keyboard Mouse Maximum Load Capacity: 4.85 lb Product Weight: 14.4 lbs (6.5 kg)
• Weight: 19.2
• Model #: 45-354-026

• Type: Mount
• Specifications: LCD Size: <= 24" Lift: 13"(33 cm) Tilt : 85° Pan: 360° Rotation: 360° P/L VESA: MIS-D Versatile: Use with a notebook and LCD or with two LCDs Weight Capacity: Maximum individual LCD weight = 7 to 20 lbs (3.1 to 9.1 kg); notebook weight range = 2.5–12 lbs (1.1–5.4 kg); maximum combined weight = 40 lbs (18.1 kg). Monitor depth may affect weight capacity Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm) Shipping Dimensions: 19.25" x 15.25" x 9" (487 x 387 x 229 mm) Shipping Weight: 15.75 lbs (7.18 kg)
• Weight: 19.20 lbs.
• Model #: 45-248-026

• Type: Mount
• Specifications: Weight Capacity: 45-241-026 = 14 lbs (6.3 kg); 45-245-026 = 6 lbs (2.7 kg) per monitor
• Model #: 98-017

• Type: Wall Track
• Specifications: OSHPD Pre-approval Number OPA-0620 Fasteners for attaching to wall not included. Fasteners may be purchased from Ergotron: part number 97-531 for metal or wood studs; part number 90-011 for hollow walls Separately-order brackets required to attach Ergotron components: part number 97-091 for LX & MX Arms, Neo-Flex Wall Mounts, 400, 200 and 100 Series Arms and Pivots, and Universal CPU Holder; part number 60-156 for Medium and Small CPU Holders Dimensions: 26" x 5" x .87" (660 x 127 x 22 mm) Shipping Weight: 4 lbs (1.8 kg)
• Weight: 4.9
• Parts: 5 years limited
• Model #: 31-017-182

• Type: Bracket
• Color: Black
• Specifications: Certifications & Standards: VESA 100/75 VESA FDMI MIS-D VESA C (hole pattern: 100 x 100 mm & 75 x 75 mm) Load Capacity: 35 lb Maximum Color: Black
• Weight: 1.15 lbs.
• Model #: 60-589-060

• Model #: 9391048894531

• Type: Mount
• Specifications: Includes (6) Phillips oval head CR, ST6.3 x 2.5 - 50 mm (2") screws and (6) Phillips oval head self-tapping CR, ST6.3 x 1.8 - 50 mm (2") screws
• Weight: 0.35
• Parts: 3 years limited
• Model #: 97-531

• Type: Mount
• Model #: BE45B475E216

• Model #: 9391048943468

• Type: 42" Wall Track
• Specifications: Wall Track is a low-cost, zero-footprint mounting system that attaches to most vertical surfaces. It accommodates an entire computer workstation. Separately-ordered brackets are required to attach components to Wall Track (view + Accessories). The height of components can be adjusted by loosening set-screws on these brackets. Description: 42" Wall Track (aluminum) with cable management channel covers Dimensions: 42" x 5" x .87" (1067 x 127 x 22 mm) OSHPD Pre-approval Number OPA-0620 Fasteners for attaching to wall not included. Fasteners may be purchased from Ergotron: part number 97-531 for metal or wood studs; part number 90-011 for hollow walls Separately-order brackets required to attach Ergotron components: part number 97-091 for LX & MX Arms, Neo-Flex Wall Mounts, 400, 200 and 100 Series Arms and Pivot...
• Model #: 31-039-182

• Type: Wall Mount Arm
• Specifications: Colour: black Includes 200 Wall Mount Pivot, wall mount bracket, 1 extension, VESA mounting screws Extends up to 14.8" (37.6 cm) from the wall and retracts to within 5.8" (14.8 cm), excluding depth of monitor Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm) Weight Capacity: 25 lbs (11.3 kg) Monitor depth greater than 3" (7.5 cm) may diminish capacity Durable, easy-to-clean powder-coated painted steel exterior Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud
• Weight: 7.36
• Parts: 3 years limited
• Model #: 45-233-200

• Type: Monitor Arm
• Specifications: Device Supported: Flat Panel Display Maximum Load Capacity: 25.00 lb Maximum Screen Size Supported: 42" Color: Polished Aluminum VESA Mount Compatible: Yes VESA Mount Standard: 75 x 75, 100 x 100, 200 x 100, 200 x 200 Height: 20.0" Depth: 33.0" Weight (Approximate): 11.00 lb
• Weight: 12.7
• Model #: 45-353-026

• Type: Single-Monitor Stand
• Specifications: LCD Size: < 24" Weight Capacity: 6–16 lbs (2.7–7.2 kg) Lift: 5", 13 cm Tilt: 30° Pan: 270° Rotation: 90° P/L VESA: MIS-D Description: Neo-Flex LCD Desk Stand (black & silver) Meets UL Specification 1678 Tip Test when loaded with all weights of LCDs Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
• Weight: 5.75
• Parts: 3 years limited
• Model #: 33-310-060

• Type: Kit
• Color: Black
• Specifications: Description: Tall-User Kit for WorkFit Dual Includes two (2) single monitor pivots, two (2) riser brackets, installation hardware * Maximum outside width of display is 21.25" (54 cm) when displays are 2" (5 cm) thick. This is typically the horizontal dimension of a 22" diagonal screen-size monitor. Actual allowable width of displays will vary slightly depending on display thickness ** Weight Capacity: 6 - 14 lbs. (2.7 - 6.3kg) per display, 12 - 28 lbs. (5.5 - 12.7kg) combined Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
• Model #: 97-615

• Type: Mount
• Parts: 3 years limited
• Labor: 3 years limited
• Model #: 97-487-800

• Model #: 45245026

• Type: Mount
• Specifications: LCD Size: < 24" Wt. Capacity: 6–16 lbs, 2.7–7.2 kg Lift: 5", 13 cm Tilt: 35° Pan: 70° Rotation: 90° P/L VESA: MIS-D Description: Neo-Flex Wall Mount Lift (black) Monitor depth greater than 2" (5 cm) may diminish capacity. Read more Mounting Standards: VESA FDMI, MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm) Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. To increase support, a separately-ordered Wall Track accessory is recommended
• Weight: 5.15
• Parts: 5 years limited
• Model #: 60-577-195

• Type: Others
• Model #: 45-245-224

• Type: Misc
• Model #: 45-490-216

• Type: Monitor clamping double pivot
• Specifications: Display size is dependent on overall configuration of the DS100 Stand; observe balance requirements to prevent tipping Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm) Attaches to DS100 Pole only; cannot attach to DS100 Crossbar
• Weight: 5
• Parts: 5 years limited
• Model #: 47-051-200

• Type: Wall Mount LCD Arm
• Specifications: LCD Size: = 30" Capacity: 14–30 lbs* Lift: 5" Tilt: 80° Rotation: 90° P/L
• Weight: 9.85
• Parts: 3 years limited
• Model #: 45-228-026

• Type: Wall Plate
• Specifications: Easy to install. Strong, steel construction. Color: Black
• Weight: 0.8
• Parts: 5 years limited
• Model #: 60-254-007

• Type: Mount
• Color: Polished Aluminum
• Specifications: Includes Includes: 10" and 34" Wall Tracks with two black track covers, LX Wall Mount LCD Arm, LX Keyboard Arm, wrist rest, mouse pad, mouse holder, Small CPU Holder, two 10" Cable Channels, mounting kits for hollow-wall and wall-stud installation Quality Tested: 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment Polished aluminum construction offers greater durability and enhanced aesthetics Snap-fit cap secures interface of arms to extensions for greater stability Weight Capacity: display = 7-25 lbs (3.2-11.3 kg); keyboard = 5 lbs (2.2 kg); CPU = 50 lbs (22 kg). With monitors greater than 20 lbs (9.1 kg) in weight, the vertical range of motion may be reduced up to 4.5" (11 cm) for a total height range of 8.5" (22 cm) Mounting Standards: VESA FDMI MIS...
• Model #: 45-253-026

• Type: Multi-Monitor Stand
• Specifications: LCD Size: Up to 24"(Up to 61 cm) Weight Capacity: Up to 23 lbs(Up to 10.35 kg) Tilt: 180° Pan: 180° Rotation: 360° P/L VESA: MIS-D DS100 Dual-Monitor Desk Stand, Vertical (black) Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm) Shipping Dimensions: 28" x 16" x 7.5" (711 x 406 x 191 mm) Shipping Weight: 16 lbs (7.3 kg)
• Weight: 15.3
• Parts: 5 years limited
• Model #: 33-091-200

• Type: Mount
• Color: Black
• Specifications: LCD Size: <= 24" Weight Capacity: <= 25 lbs. Tilt: 180 degree Pan: 180 degree Rotation: 360 degree P/L Certifications & Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
• Weight: 4.50 lbs.
• Model #: 45-232-200

• Type: T-Slot Bracket Kit
• Specifications: Description: Interface Bracket Kit (aluminum); aka T-Slot Bracket Kit Includes: (1) Angled T-Slot Interface Bracket, (2) Light-Duty T-Slot Brackets, mounting hardware, manual Light-Duty Brackets can be used with most Ergotron carts; Angled Interface Bracket can be used with Neo-Flex Mobile WorkSpace Carts, Mobile MediaCenters, StyleView 31/32 Carts and WorkFit C-Mod Workstations Install either the Angled Interface Bracket or the Light-Duty Brackets; to deploy both types of brackets on a cart requires two kits Consideration should be given to weight of component being mounted relative to its height on cart to avoid tip hazard
• Parts: 3 years limited
• Labor: 3 years limited
• Model #: 60-587-207

• Type: Monitor Arm and Mount
• Color: Polished Aluminum
• Specifications: Screen: <= 34.00" Lift: 13.00" (33.00 cm) Tilt Range: 70 degrees backward, 5 degrees forward Pan: 360 degress Rotation: 360 degrees VESA: MIS-D Mounting Options: Desk Clamp attaches to surface edge 0.40" to 2.40" (10.00 to 60.00 mm) thick; Grommet Mount attaches through surface holes 0.31" to 2.00" (8.00 to 50.00 mm) wide and up to 2.25" (57.00 mm) thick Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100.00 x 100.00 mm & 75.00 x 75.00 mm) Weight Capacity: 7.00 to 25.00 lbs. (3.20 to 11.30 kg). With monitors greater than 20.00 lbs. (9.10 kg) in weight, the vertical range of motion may be reduced up to 4.50" (11.00 cm) for a total height range of 8.50" (22.00 cm) Note: If installed on WorkFit-T or WorkFit-TL, maximum allowable monitor weight is reduced to 14.00 l...
• Model #: 45241026

• Type: Wall Mount
• Specifications: LCD Size: < 27" Wt. Capacity: <30 lbs, <13.6 kg Description: FX30 Fixed Wall Mount (black) Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm) For larger hole patterns (200 x 100 mm, 200 x 200 mm or 400 x 200 mm TUV-GS Safety Certificate Shipping Dimensions: 7" x 7" x 2" (178 x 178 x 51 mm) Shipping Weight: 2 lbs. (0.9 kg)
• Weight: 2.2
• Parts: 5 years limited
• Model #: 60-239-007

• Type: Others
• Model #: 97-818

• Color: White
• Model #: 98540216

• Type: Others
• Features: Sold as 1 Each.
• Model #: 98-101-009

• Type: Single-Monitor Stand
• Specifications: Weight Capacity: 6–16 lbs (2.7–7.2 kg) for display; total stand capacity = 37 lbs (16.7 kg) for combined weight of display, CPU, keyboard and mouse Motion may be restricted when using 22"–24" monitors in portrait mode Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm) Five-inch (13 cm) height adjustment ergonomically accommodates average range of users Meets tip test requirements of UL Specification 1678 + Removal of lock screw allows portrait to landscape rotation (90°) Compatible with most 15"–24" displays, and most small or ultra small form factor CPUs. Maximum CPU size = 15"W x 14"H x 4.5"D (38 x 35.6 x 11.4 cm); minimum CPU size = 7"W x 7"H x 2"D (18 x 18 x 5.1 cm). Provided rubber spacer must be used to accommodate CPU depths of less than 3" (7.6 cm) Moun...
• Model #: 33-338-085

• Type: Monitor Arm
• Color: Silver
• Specifications: Screen <= 46" Capacity: 14 - 30 lbs. Lift: 20" Tilt: 80 Degree Pan: 360 Degree Rotation: 90 Degree Vesa: MIS-D/E/F
• Weight: 17.50 lbs.
• Model #: 45-384-026

OUT OF STOCK

• Type: Mount
• Weight: 10.7
• Parts: 3 years limited
• Labor: 3 years limited
• Model #: 45-246-026
