Specifications: Device Supported: Flat Panel Display, Notebook
Maximum Load Capacity: 25.00 lb
Maximum Screen Size Supported: 42"
Color: Polished Aluminum
VESA Mount Compatible: Yes
VESA Mount Standard: 75 x 75, 100 x 100
Weight (Approximate): 8.75 lb
Specifications: Includes 10" and 34" Wall Tracks with (2) black track covers, LX Sit-Stand Wall Mount LCD Arm, LX Sit-Stand Keyboard Arm, wrist rest, mouse holder, Medium CPU Holder, two (2) 10" Cable Channels, mounting kits for hollow-wall and wall-stud installation
Quality Tested: 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment
Weight Capacity: display = 7-25 lbs (3.2-11.3 kg); keyboard = 5 lbs (2.2 kg); CPU = 40 lbs (18 kg). Monitor depth may affect weight capacity. Read more
Monitor tilts 70 degrees up and 5 degrees down
Rotation Stop on wall-mount base limits turn of extension-base connection to 180 degrees, preventing extension from contacting wall
Locking connections between arm, extension and base offer increased theft deterrence and prevent potential disconnections caused by j...
Specifications: Includes mouse pad, wrist rest, mouse pouch
+ Larger display sizes may inhibit the keyboard tray folding flat in storage position
Weight Capacity: Listed weight capacity represents total load, including both the monitor and contents of keyboard tray. Maximum monitor weight = 25 lbs (11.3 kg); monitor thickness greater than 3" (7.6 cm) may decrease capacity
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Fold-down keyboard tray
Negative-tilt keyboard tray is adjustable 0° to -10°
Integrated cable management system can be configured on either side
Easy-to-clean exterior
Specifications: Weight Capacity: 6–16 lbs (2.7–7.2 kg) for display; total stand capacity = 37 lbs (16.7 kg) for combined weight of display, CPU, keyboard and mouse
Motion may be restricted when using 22"–24" monitors in portrait mode
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Five-inch (13 cm) height adjustment ergonomically accommodates average range of users
Meets tip test requirements of UL Specification 1678 + Removal of lock screw allows portrait to landscape rotation (90°)
Compatible with most 15"–24" displays, and most small or ultra small form factor CPUs.
Maximum CPU size = 15"W x 14"H x 4.5"D (38 x 35.6 x 11.4 cm); minimum CPU size = 7"W x 7"H x 2"D (18 x 18 x 5.1 cm). Provided rubber spacer must be used to accommodate CPU depths of less than 3" (7.6 cm)
Moun...
Specifications: Recommended Use: LCD display / keyboard / mouse / CPU
Recommended Display Size: 30"
Flat Panel Mount Interface: 100 x 100 mm, 75 x 75 mm, 200 x 200 mm, 400 x 200 mm
Max Load Weight 28 lbs
Color: Gray, black
Adjustable height, rotating, tilt, locking casters, cable box
Specifications: Screen: <= 34.00"
Lift: 13.00" (33.00 cm)
Tilt Range: 70 degrees backward, 5 degrees forward
Pan: 360 degress
Rotation: 360 degrees
VESA: MIS-D
Mounting Options: Desk Clamp attaches to surface edge 0.40" to 2.40" (10.00 to 60.00 mm) thick; Grommet Mount attaches through surface holes 0.31" to 2.00" (8.00 to 50.00 mm) wide and up to 2.25" (57.00 mm) thick
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100.00 x 100.00 mm & 75.00 x 75.00 mm)
Weight Capacity: 7.00 to 25.00 lbs. (3.20 to 11.30 kg). With monitors greater than 20.00 lbs. (9.10 kg) in weight, the vertical range of motion may be reduced up to 4.50" (11.00 cm) for a total height range of 8.50" (22.00 cm)
Note: If installed on WorkFit-T or WorkFit-TL, maximum allowable monitor weight is reduced to 14.00 l...
Specifications: Weight Capacity: Display 6–18 lbs (2,7–8,2 kg); keyboard, mouse and barcode scanner 4 lbs (1,8 kg) and up to 10 lbs (4,5 kg) on worksurface
Pan: 360°
Rotation: 90°
Specifications: Weight Capacity:
Display = 6 - 18 lbs. (2.7 - 8.2kg) or up to 25 lbs (11.4kg) with tilt and lift lock-out features engaged
keyboard, mouse and barcode scanner = 4 lbs (1.8kg)
CPU = 50 lbs (22.7kg)
Lift: 25" (64cm)
Tilt: Up +25 degree/ Down -5 degree
Mounting Pattern: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Pan: 360 degree
Rotation: 360 degree
Keyboard Tray Dimensions: 18.6" x 9" (47.2 x 22.8cm)
CPU Dimension: 1-3/8" to 3-3/4" (35 to 95mm) wide; accommodates most small form factor and ultra small form factor CPUs
Monitor Size: Up to 24"
Specifications: Complies with UL Tip Standards 1667 and 1678
Rugged plastic-composite shelf conveniently attaches to cart at any height
Modular cable channel system is adaptable for various wiring configurations
Add the MMC Camera Shelf Kit to place adjustable camera shelf above the display (ordered separately); shelf is not compatible with the NF MMC LD, 24-190-057, when using the optional small LCD monitor pivot (includes 75 mm and 100 mm mounting holes), which is typically used with 25 lbs (11. 4 kg) to 36 lbs (16.3 kg) displays. As an alternative, the NF WideView cart, 24-189-055, does accommodate this size monitor and a camera shelf
CPUs attach safely to rear of cart with Universal CPU Holder accessory (ordered separately). Compatible with CPU sizes from 12" H x 3" D to 18" H x 8.5" D (300 x 80 mm to 460 x 220 mm)...
Features: Increases the reach of an LX Arm
Polished aluminum metal construction offers greater durability and enhanced aesthetics
Adds another pivot-point for more adjustment flexibility
Cable management feature routes cables under the arm, out of the way
Specifications: Description: Spacer kit for mounting to 75 x 75 mm recessed monitors (black)
Includes (1) spacer and (4) Phillips pan head M4 x 25 mm screws
Specifications: Description: Worksurface for WorkFit-S Sit-Stand Workstations (black)
Includes worksurface, mounting brackets with integrated handle, and mounting hardware
Worksurface Dimensions: 0.25" H x 23" W x 15 "D (6 x 585 x 380 mm)
Cannot be added to system where Tablet/Document Holder accessory 97-558-200 is installed
Installation of the worksurface will not impact normal 20" (51 cm) range of sit-stand height adjustment, but may impact the relative vertical adjustment of larger displays when in portrait orientation
When this accessory is added to the WorkFit-S, total weight capacity of the workstation is reduced by 6 lbs (2.7 kg)
Specifications: Description: DS100 Crossbar Extender, Long (black)
Includes: Long Extenders, Center Display Bracket, Attachment hardware
Display: Maximum physical outside width of display = 24.5" (62 cm). This is slightly more than typical display with a 26" screen.
Weight Capacity: 31 lbs (14 kg) per monitor
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
