Specifications: Description: Interface Bracket Kit (aluminum); aka T-Slot Bracket Kit
Includes: (1) Angled T-Slot Interface Bracket, (2) Light-Duty T-Slot Brackets, mounting hardware, manual
Light-Duty Brackets can be used with most Ergotron carts; Angled Interface Bracket can be used with Neo-Flex Mobile WorkSpace Carts, Mobile MediaCenters, StyleView 31/32 Carts and WorkFit C-Mod Workstations
Install either the Angled Interface Bracket or the Light-Duty Brackets; to deploy both types of brackets on a cart requires two kits
Consideration should be given to weight of component being mounted relative to its height on cart to avoid tip hazard
Specifications: Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
LCD Size: 30"
Capacity: 31 lbs
Rotation: 360° P/L
Attaches to Crossbar and Crossbar Extenders
Cannot be used as the Center Display Bracket when three displays are attached to Crossbar
Install displays with 4°-angle off-set : position them upward, inward or downward for optimized viewing conditions
Specifications: Glide Wall Mount will be hidden behind display in most cases when used with screen size of 46" or greater; when used with screens smaller than 46", the mount may be visible
Mounting holes must fit within spacing range below:
Horizontal = 200 mm (min.) to 400 mm (max.)
Vertical = 100 mm (min.) to 400 mm (max.)
Includes low-profile lift module, mounting template, tilt brackets, installation and mounting hardware, cable management hardware
Specifications: LCD Size: < 27"
Wt. Capacity: <30 lbs, <13.6 kg
Description: FX30 Fixed Wall Mount (black)
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
For larger hole patterns (200 x 100 mm, 200 x 200 mm or 400 x 200 mm
TUV-GS Safety Certificate
Shipping Dimensions: 7" x 7" x 2" (178 x 178 x 51 mm)
Shipping Weight: 2 lbs. (0.9 kg)
Specifications: Upgrade your WorkFit to hold a larger LCD above the desktop. Offers 5" (13 cm) of height adjustment and tilt. Easily lift and tilt the screen to proper height for unsurpassed ergonomic comfort.
Specifications: Includes mouse pad, wrist rest, mouse pouch
+ Larger display sizes may inhibit the keyboard tray folding flat in storage position
Weight Capacity: Listed weight capacity represents total load, including both the monitor and contents of keyboard tray. Maximum monitor weight = 25 lbs (11.3 kg); monitor thickness greater than 3" (7.6 cm) may decrease capacity
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Fold-down keyboard tray
Negative-tilt keyboard tray is adjustable 0° to -10°
Integrated cable management system can be configured on either side
Easy-to-clean exterior
Specifications: Device Supported: Flat Panel Display
Maximum Load Capacity: 25 lb
Maximum Screen Size Supported: 42"
Color: Polished Aluminum
VESA Mount Standard:
75 x 75
100 x 100
200 x 100
200 x 200
Specifications: Compatibility: <=24" LCD
Weight Capacity: 5-30 lbs(2.3-13.6 kg)
Lift: 9"(22.9 cm)
Tilt: 10°
VESA: MIS-D
Additional Information:
Negative-tilt keyboard tray is adjustable 0° to -10°
Maximum Monitor Weight = 25 lbs (11.3 kg)
Monitor thickness greater than 3" (7.6 cm) may decrease capacity
Integrated Cable Management System can be Configured on Either Side
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Package Contents:
StyleView 60-593-195 Vertical Mount Lift
Mouse Pad
Wrist Rest
Mouse Pouch
Features: Increases the reach of an LX Arm
Polished aluminum metal construction offers greater durability and enhanced aesthetics
Adds another pivot-point for more adjustment flexibility
Cable management feature routes cables under the arm, out of the way
Specifications: Includes (6) Phillips oval head CR, ST6.3 x 2.5 - 50 mm (2") screws and (6) Phillips oval head self-tapping CR, ST6.3 x 1.8 - 50 mm (2") screws
Specifications: Includes 10" and 34" Wall Tracks with (2) black track covers, LX Sit-Stand Wall Mount LCD Arm, LX Sit-Stand Keyboard Arm, wrist rest, mouse holder, Medium CPU Holder, two (2) 10" Cable Channels, mounting kits for hollow-wall and wall-stud installation
Quality Tested: 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment
Weight Capacity: display = 7-25 lbs (3.2-11.3 kg); keyboard = 5 lbs (2.2 kg); CPU = 40 lbs (18 kg). Monitor depth may affect weight capacity. Read more
Monitor tilts 70 degrees up and 5 degrees down
Rotation Stop on wall-mount base limits turn of extension-base connection to 180 degrees, preventing extension from contacting wall
Locking connections between arm, extension and base offer increased theft deterrence and prevent potential disconnections caused by j...
Specifications: LCD Size: < 24"
Wt. Capacity: < 25 lbs, 11.3 kg
Tilt: 180°
Rotation: 360° P/L
VESA: MIS-D
Description: Neo-Flex Dual Monitor Wall Mount
Includes two (2) 100 Series Single Pivots, 26" Wall Track, two (2) Track Mount Bracket Kits
Mounting Standards: VESA FDMI, MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Specifications: Includes handle, basket, mounting hardware
Internal dimensions of basket: 5.875"H x 13.25"W x 3.125"D (149 x 337 x 79 mm)
Durable plastic and metal design
Designed for the StyleView EMR Laptop Cart, SV40. Also compatible with other StyleView 41/42-Series EMR Carts, which come standard with this basket and handle
Attaches to rear of cart using a single t-slot channel bracket
Weight Capacity: 5 lbs (2.3 kg)
Specifications: Upgrade your WorkFit to hold an LCD above the desktop. Offers 5" (13 cm) of height adjustment and tilt. Easily lift and tilt the screen to proper height for unsurpassed ergonomic comfort.
Features: Holds display above worksurface, freeing up space
Cost-effective height-adjustable mounting solution
Simple installation and effortless operation
Patented CF motion technology provides premium ease-of-use display adjustment
Increase viewing comfort by reducing eye, back and neck strain
Add an accessory Notebook Tray to use with a laptop computer and external keyboard
Specifications: Weight Capacity: Display 6–18 lbs (2,7–8,2 kg); keyboard, mouse and barcode scanner 4 lbs (1,8 kg) and up to 10 lbs (4,5 kg) on worksurface
Pan: 360°
Rotation: 90°
Specifications: Device Supported: CPU, Flat Panel Display, Keyboard, Mouse
Maximum Load Capacity: 25.00 lb
Maximum Screen Size Supported: 42"
Color: Black
VESA Mount Compatible: Yes
VESA Mount Standard: 75 x 75, 100 x 100, 200 x 100, 200 x 200, 400 x 200, 400 x 300, 400 x 400
Material: Aluminum
Weight (Approximate): 39.00 lb
Specifications: Device Support: Flat Panel Display
Load Capacity: 6-18 lb Maximum for Display
5 lb Maximum for Keyboard, mouse and barcode scanner
Maximum Screen Size Support: 24"
Rotation: 30° - Tilt
Pan: 360°
Rotation: 90°
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Integrated mouse and barcode scanner holder provide easy access
Integrated fold-down keyboard tray with right/left mouse tray (includes built-in mouse pad surface)
Negative-tilt keyboard tray adjustable 0 to -10 degrees
Durable, easy-to-clean exterior composed of aluminum, high-grade plastic and powder-coated painted steel
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. Separately ordered Wall Track or Wall Plate accessory is recommended to strengthen...
