Specifications: RoHS: Compliant
REACH: Contains No SVHCs REACH SVHCs
PEP: Available in Documentation tab
REACH REACH: Contains No SVHCs
EOLI: Available in Documentation tab
Compatibility: CyberPower Systems Smart App Sinewave UPS Systems
CyberPower Systems Smart App Intelligent LCD/AVR UPS Systems* (CPS1500AVR UPS system is NOT supported)
CyberPower Systems Automatic Transfer Switch (ATS) Power Distribution Units (PDU)
Please see RMCARD Compatibility Chart in the Resources section for details
Note: *UPS systems manufactured in or before 2010 may have a ribbon cable coming out of the RMCARD port and are not compatible with the RMCARD205.
Specifications: System Requirements:
An Ethernet network connection
Web Browser
Network Management System (NMS) compliant with SNMPv1/v3 (optional)
Specifications: Output
Output Power Capacity: 3200 Watts / 4000 VA
Max Configurable Power: 3200 Watts / 4000 VA
Nominal Output Voltage:120V,208V
Output Voltage Note: Configurable for 120/208 or 120/240 output voltage
Output Voltage Distortion: Less than 5% at full load
Output Frequency (sync to mains): 47 - 63 Hz
Waveform Type: Sine wave
Output Connections: (1) Hard Wire 4-wire (2PH + N +G)
Input
Nominal Input Voltage: 200V,208V
Input Frequency: 45 - 65 Hz (auto sensing)
Input voltage range for main operations: 155 - 276V
Other Input Voltages: 240V
