Extenders & Repeaters

• Type: HDMI over Ethernet
• Max Extend Distance: 328 feet
• Color: Black
• Specifications: Audio: Supports high-definition audio (HD) 5.1/6.1/7.1 surround sound: Dolby TrueHD, DTS-HD Master Audio LPCM channels up to 7.1 channels 192 kHz Operating Humidity: 0 to 80% relative humidity Operating Temperature: 32° to 122° F (0° to 50° C) PoE: Complies with IEEE 802.3at standard, Class 4; Power: Normal input: 48 VDC; Input Range: 36 to 57 VDC Power: (1) External 5 VDC, 3 A Power Consumption: POE: 10.5 W Storage Temperature: -4° to +140° F (-20° to +60° C) User Controls: B1: Set/Reset Pushbutton; B2: Function Selection Pushbutton; Rotary switch: Select from 16 Video Channels (HEX 0–F), Paired TX and RX units must use the same channel
• Model #: VX-HDMI-HDIP-RX

• Color: Black
• Specifications: Interfaces IR/Serial 6 x Programmable IR / Uni-directional RS-232 Port 6 x 2-Pole Terminal Block Connector IR: TTL level (0 to 5 V) Carrier Frequency: 10 - 455 KHz; Serial: Uni-directional RS-232 ( + - 5 V) Baud Rate: 300 to 115200 (default: 9600); Data Bit: 8 (default) or 7; Stop Bit: 1 (default) or 2; Parity: None (default), Even or Odd Ethernet 1 x RJ-45 Female, 10/100Base-T Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds: IP: 192.168.0.60 Subnet Mask: 255.255.255.0 Switches Controller ID: 1 x 16-segment Switch Expander ID: 1 x 8-segment Switch Reset Button: 1 x Semi-recessed Pushbutton USB: 1 x USB Type A (Firmware upgrade only) Power: Consumption 5VDC, 8W(adapter); 48V, 10.5W (PoE, PoE 802.3 AF/AT compatibility)...
• Model #: VK236

• Color: Black
• Specifications: Interfaces Serial 4 x Programmable Bi-directional RS-232/422/485 Port (4 x DB9 Male Connector, configurable via pin assignments); Baud Rate: 300 to 115200 (default: 9600); Data Bit: 8 (default) or 7; Stop Bit: 1 (default) or 2; Parity: None (default), Even or Odd; Flow Control: None (default) RTS/CTS Ethernet 1 x RJ-45 Female, 10/100Base-T Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds: IP: 192.168.0.60 Subnet Mask: 255.255.255.0 Switches Controller ID: 1 x 16-segment Switch Expander ID: 1 x 8-segment Switch Reset Button: 1 x Semi-recessed Pushbutton USB: 1 x USB Type A Power: Consumption 5 VDC, 7.5 W(adapter) ; 48VDC, 9.5 W(PoE, PoE 802.3 AF/AT compatibility)
• Dimensions: 1.65" x 2.98" x 5.12"...
• Model #: VK224

• Type: HDMI & USB over Ethernet
• Max Extend Distance: 131 feet
• Color: Black
• Specifications: VE803T Connectors HDMI In: 1 x HDMI Type A Female (Black) USB: 1 x USB Type B Female (White) HDMI/USB Port: 2 x RJ-45 Female (Silver) Power: 1 x DC Jack Switches: EDID Selection: 1 x slide switch LEDs Power: 1 (Green) Video: 1080p @ 60Hz, at 40m 1080i @ 60Hz, at 60m Power Consumption: DC5V, 1W PhysicalProperties Housing: Metal VE803R Connectors HDMI Out: 1 x HDMI Type A Female (Black) USB: 1 x USB Type A Female(White) HDMI/USB Port: 2 x RJ-45 Female (Silver) Power: 1 x DC Jack Switches EQ Compensation: 1 x 8 position switch LEDs Power: 1 (Green) HDMI: 1 (Green) USB: 1 (Green) Video: 1080p @ 60Hz, at 40m 1080i @ 60Hz, at 60m Power Consumption: DC5V, 3.9W PhysicalProperties Housing: Metal
• Model #: VE803

• Color: Black
• Specifications: Interfaces Relay 8 normally open relays (8 x 2-pole terminal block) Contact Rating: Max 24 VDC, 2A Ethernet 1 x RJ-45 Female, 10/100Base-T Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds: IP: 192.168.0.60 Subnet Mask: 255.255.255.0 Switches Controller ID: 1 x 16-segment Switch Expander ID: 1 x 8-segment Switch Reset Button: 1 x Semi-recessed Pushbutton USB: 1 x USB Type A (Firmware upgrade only) Power Consumption 5 VDC, 10 W (Adapter); 48 VDC, 13 W (PoE, PoE 802.3 AF/AT compatibility) Output 12 VDC, 300 mA
• Dimensions: 1.65" x 2.98" x 7.87"
• Weight: 1.43 lbs.
• Model #: VK248

• Specifications: Connectors Video In: 1 x HDB-15 Male (Blue) Video Out: 1 x HDB-15 Female (Blue) Audio In: 1 x Audio Jack Female (Green) Audio Out: 1 x Audio Jack Female (Green) Unit to Unit: 1 x RJ-45 Female Power: 1 x DC Jack LEDs Power: 1 (Green)VE170R, VE170RQ Switch Manual Gain Control: 2 x Knob (VE170R, VE170RQ) RGB Tuner: 3 x Knob (VE170RQ) Cable Distance: 1000 feet (300 m) Power Consumption VE170T: DC 5.3V, 0.9W VE170R: DC 5.3V, 1.11W VE170RQ: DC5.3V, 4.82W Video VE170T, VE170R: 1920 x 1200 at 60Hz, 100 feet(30 m) 1600 x 1200 at 60Hz, 500 feet(150 m) 1024 x 768 at 60Hz, 1000 feet(300 m) VE170RQ: 1920 x 1200 at 60Hz, 500 feet(150 m) 1280 x 1024 at 60Hz, 1000 feet(300 m)
• Dimensions: 0.90" x 3.40" x 4.70" (H x W x D)
• Weight: 0.60 lb.
• Model #: VE-170Q

• Type: HDMI, USB, Serial, IR, Audio
• Max Extend Distance: CATx: 328 feet. (100 m); single-mode fiber (SFP): up to 30 km
• Color: Black
• Specifications: HDMI 4K video over IP This attractively priced IP video distribution solution uses existing standards-based Ethernet technology and TCP/IP protocols to unicast HDMI 4K video signals on your Gigabit Ethernet network. In a multicast configuration, one transmitter can drive multiple receivers with no extra network load. Plug-and-play setup Because the transmitter and receiver install directly into your existing LAN infrastructure, integration is easy. And you don't have to configure any IP settings. Connect your source, your display, a network switch, and you're ready go. PoE support for remote powering The MediaCento IPX 4K is PoE powered eliminating the need for power supplies. Using a PoE netwo...
• Model #: VX-HDMI-4KIP-RX

• Type: HDMI Extender
• Max Extend Distance: 131 ft. (40m)
• Changer Type: HDMI
• Color: Black
• Model #: IDATA HDMI2-RIP4KT

• Type: HDMI Extender
• Max Extend Distance: 45 feet
• Color: Black
• Specifications: Audio Specifications; DTS / Dolby Digital Bandwidth: 18Gbps Max Distance: 14 m / 45 ft Video Revision: HDMI 2.0 Wide Screen Supported: Yes Plug Type: USB Micro-B Power Consumption (In Watts): <2.5 Power Source: Not Included (not required for standard applications)
• Model #: HDBOOST4K2

• Type: HDMI over Ethernet
• Max Extend Distance: 164 feet
• Color: Black
• Weight: 8.00 oz
• Model #: CHE-1

OUT OF STOCK

• Type: DVI-D ove Ethernet
• Max Extend Distance: 330 feet
• Color: Black
• Cable Length: 12"
• Model #: EMD200DV-T
