Dimensions: 110mm (W) x 9mm (H) x 26mm (D) / 4.33" (W) x 0.35" (H) x 1.02" (D)
Specifications: To take advantage of the increased popularity of M.2 solid state drives, SilverStone created the MS09, a premium, pocketable M.2 enclosure. It has an exquisite anodized aluminum exterior with a size that is nearly as small as common USB thumb drives. Internally, it fits M.2 SATA SSD up to 80mm so the MS09 can be used with a wide variety of new or repurposed M.2 SATA SSD from laptops and turning them into high-speed USB flash drive. To make the most of M.2 SATA SSD’s performance, it also incorporates USB 3.1 Gen 2 interface for superfast read / write and excellent compatibility. Lastly, the MS09 is designed to work without additional driver installation so you can conveniently take it anywhere and use it on nearly any PC instantly.
Data tr...
Specifications: Color: White
Cooling system: 22Pin SATA
HDD size support: 9.5mm 2.5" SSD or HDD
Tray Material: Plastic
Tray Interface: 13Pin Slimline SATA
LED indicator: Blue light LED indicate drive read/write access
Net Weight: 27g
Dimension: 128mm(W)x10mm(H)x131mm(D)
Support Laptop: PC Laptop with 9.5mm ODD bay or Macbook Pro
Specifications: Data transfer rate: USB 3.1 Gen 2 up to 10Gbps (Compatible with USB 3.1 Gen 1 / 3.0 / 2.0 / 1.1)
LED indicator :
Solid Blue: Powered
Blinking Blue: Reading / writing
Support type of M.2 SSD:
B Key SATA Type M.2 SSD x 1
Support 22mm x 60mm or 22mm x 80mm size
Controller: VIA VL715
Material: Aluminum Body, High Quality Metal, Plastic-ABS Cover
Dimensions: 2.76" x 5.51" x 4.96" w/o Feet
Specifications: SilverStone TS12 is an external hard drive docking station made to accommodate two 2.5" or 3.5" drive at speeds up to 10 Gb/s with its USB 3.1 Gen 2 capability and Type-C connector. It is packed with features such as UASP (USB Attached SCSI Protocol), so those with computers that support it can take their data transfer rate up another level. TS12's tray-less design and JBOD mode also makes it easy to setup and use with any computers. Finally, for those that wish to quickly back up or duplicate data, TS12 is also capable of operating independently by allowing for direct hard drive cloning without the need to connect to a computer.
Mobile Rack Drives Support: Multi 2.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II/III
Specifications: Host Interface: 7 pin SATA x 4
Drive Fit: 2.5" SATA I / II / III SSD or hard drive x 4
Drive Bay: Single 5.25" half height device bay
Transfer Rate: Up to 6 Gb / sec. (depending on hard drive speed)
Insert& Extract connection Via: Direct SATA hard drive connection
Structure: SECC
Device Power: Single 4 pin Molex power
Drive Cooling:
Dual 40mm rear cooling fan + fan power switch
Metal heat dispersion
Power Indicator: Solid Green LED
HDD Access Indicator: Flashing Amber LED
Dimension (L x W x H): 6.70" x 5.75" x 1.63"
Weight: 1.77 lbs.
Specifications: Chipset: ASMedia 2364
Compliant with USB 3.2 Gen 2x2 specification revision 1.0
Compatible with PCIe 3.0 x 4 specification
USB data transfer rate: Up to 20Gbps
SSD type (not included): M.2 PCIe NVMe SSD (M Key). Note: Not compatible with M.2 SATA SSDs
SSD size: 2230 / 2242 / 2260 / 2280mm
Power source: USB-C Bus-powered (5V)
UASP: Yes
Hot plug: Yes
Specifications: M.2 SSD Support: M.2 (NGFF), B Key or B+M Key
Internal Interface: 1 x M.2 (NGFF, B-Key)
External Interface: Standard USB 3.0 Micro-B
Computer Interface: USB Type A required
USB cable connector: USB 3.0 Micro-B and USB 3.0 Type-A
USB cable length: 475mm / 18 inches
