Uplink Interface: 48x 1/10/25GbE SFP28 and 8x 40/100 QSFP28 ports; one RJ-45 Ethernet port for out-of-band network management, one USB Type-C port for console management, one RJ-45 port for serial console management, and one USB Type A port for external file storage.
Power: Power / Device Type: Power Supply
Max Power Consumption: 396.2 Watt
Power / Voltage Required: AC: 100 to 240 VAC ;-48V to -60V DC
Temperature: Min Operating Temperature: 0 Celsius
Max Operating Temperature: 45 Celsius
Min Storage Temperature: - 40 Celsius
Max Storage Temperature: 70 Celsius
Power: Power / Device Type: Power Supply
Power / Installed Qty: 2
Power / Provided (W): 650 Watt
Power Consumption Operational: 336.5 Watt
Max Power Consumption: 443.1 Watt
Power / Voltage Required: 100 to 240 VAC
Temperature: Min Operating Temperature: 0 C
Max Operating Temperature: 45 C
Min Storage Temperature: -40 C
Max Storage Temperature: 70 C
Primary Ports: 16 x 10/100/1000BASE-T 802.3at (30W) ports
• Full / Half-Duplex (autosensing)
• MACsec-capable
4 x 1/10Gb SFP+ uplink ports (includes 2 x Stacking ports)
• MACsec-capable
1 x Serial console port (RJ-45)
1 x USB A ports for management or external USB flash
1 x USB Micro-B console port
PoE: All 5320 models support 30W PoE that conforms with IEEE 802.3at. This enables the 5320 to address the needs of powered edge devices, while eliminating the need for additional electrical cabling and circuits. In addition, 5320 PoE models support perpetual and fast PoE for even more efficient and reliable powered edge device operation.
Primary Ports: 48 x 10/100/1000 Base-T RJ-45 ¦ 8 x 1/10GBase-X SFP+ PoE - 30 W
1 x serial (console) RJ-45
1 x management (Gigabit LAN) RJ-45
1 x USB ¦ 1 x console (micro-USB)
PoE: All 5320 models support 30W PoE that conforms with IEEE 802.3at. This enables the 5320 to address the needs of powered edge devices, while eliminating the need for additional electrical cabling and circuits. In addition, 5320 PoE models support perpetual and fast PoE for even more efficient and reliable powered edge device operation.
Primary Ports: 24 x 10/100/1000BASE-T 802.3at (30W) ports
• Full / Half-Duplex(autosensing)
• MACsec-capable
4 x 1/10Gb SFP+ uplink ports(unpopulated)
• MACsec-capable
2 x Stacking/SFP-DD ports* (unpopulated)
1 x Serial console port (RJ-45)
1 x 10/100/1000BASE-T out-of-band management port
2 x USB A ports for management or external USB flash
1 x USB Micro-B console port
VLAN Support: Yes
PoE: All 5420 models support 30W, 60W, and 90W PoE that conforms with IEEE 802.3bt. This enables the 5420 to address the needs of powered edge devices, while eliminating the need for additional electrical cabling and circuits. In addition, 5420 PoE models support perpetual and fast PoE for even more efficient and reliable powered edge device operation
Primary Ports: 48 x 10/100/1000Base-T 802.3at (30W) ports
• Full/Half-Duplex (autosensing)
• MACsec-capable
8 x 1Gb SFP uplink ports (includes 2 x Stacking ports @ 10Gb)
• Can be upgraded to 10Gb SFP+ via software license
• MACsec-capable
• 100Mb operation supported on last 4 uplink ports
1 x Serial console port (RJ-45)
1 x USB A ports for management or external USB flash
1 x USB Micro-B console port
PoE: All 5320 models support 30W PoE that conforms with IEEE 802.3at. This enables the 5320 to address the needs of powered edge devices, while eliminating the need for additional electrical cabling and circuits. In addition, 5320 PoE models support perpetual and fast PoE for even more efficient and reliable powered edge device operation.
Primary Ports: 24 x 10/100/1000BASE-T 802.3bt (90W) ports
• Full / Half-Duplex(autosensing)
• MACsec-capable
4 x 1/10/25Gb SFP28 uplink ports (unpopulated)
• MACsec-capable
2 x Stacking/SFP-DD ports* (unpopulated)
1 x Serial console port (RJ-45)
1 x 10/100/1000BASE-T out-of-band management port
2 x USB A ports for management or external USB flash
1 x USB Micro-B console port
Primary Ports: 48 x 10/100/1000BASE-T ports
• Full / Half-Duplex(autosensing)
• MACsec-capable
4 x 1/10Gb SFP+ uplink ports(unpopulated)
• MACsec-capable
2 x Stacking/SFP-DD ports* (unpopulated)
1 x Serial console port (RJ-45)
1 x 10/100/1000BASE-T out-of-band management port
2 x USB A ports for management or external USB flash
1 x USB Micro-B console port
