Specifications: Video compression:
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG
Resolution:
176x144/176x120 (PAL/NTSC) to 720x576/720x480 (PAL/NTSC)
Frame rate:
25/30 fps in all resolutions
Up to 30 fps in quad view in full resolution
Video streaming:
Multiple, individually configurable streams in H.264, H.265 and
Motion JPEG
Axis Zipstream technology in H.264 and H.265
Controllable frame rate and bandwidth
VBR/MBR H.264/H.265
Quad view
Power:
8-28 V DC, max 4.7 W
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Connectors:
Four analog composite video BNC input
RJ45 10BASE-T/100BASE-T/1000 BASE-T PoE
RS485/RS422, 2 pcs, 2 pos, full duplex, terminal block
Storage:
...
Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features
Support for input video resolutions up to 2048x2160 pixels
HDMI Specific Features:
225MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio/SPD/MS/VS/ACP/IRSC1/ISRC2/ Gamut InfoFrames
Full colorimetry support
Support for 8/10/12-bit color depths
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for up to 8-channel IEC60958/IEC61937 audio streams
Support for extraction of audio formation information & channel status data
Supp...
Specifications: Hardware
Audio: Yes
Converter Type: Format Converter
Industry Standards: MPEG4 (H.264)
Performance
Audio Specifications: 2-channel stereo audio
Maximum Analog Resolutions: 1920 x 1200 60 FPS
Supported Resolutions: 1920 x 1200, 1920 x 1080, 1280 x 720, 1024 x 768, 800 x 600
Wide Screen Supported: Yes
Connector(s)
Connector A:
- 1 x 3.5 mm Mini-Jack (3 Position) Female Input
- 1 x DVI-I (29 pin) Female Input
Connector B: 1 x USB Type-B (9 pin) USB 3.0 Female
Power
Power Source: USB-Powered
Environmental
Humidity: 20% to 80% (non-condensing)
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -5°C to 40°C (23°F to 105°F)
Physical Characteristics
Product Height: 0.96"
Product Length: 3.63"
Product Width: 2.41"
Product Weight: 3.60 oz.
System Requirements: OS Compatibility: Windows 10, ...
Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software:
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features: Support for input video resolutions up to 2048x1080 pixels
SDI Specific Features:
Integrated cable equalizer supporting cable lengths up to 230M for HD signals
Support for SD/HD/3Ga/3Gb/3Ga-DL/3Gb-DS standards
Support for 2K (2048x1080) mode
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for 10/12-bit color depth
Support for extraction of SMPTE 352 payload identifier
Support for up to 8 (mono) audio channels at 48KHz (channels 1-8 from the 16 available in the SDI spec)
Support for extraction of audio format...
Specifications: Max Pass-Through Resolutions:1080p60
Max Record Resolutions:1080p60
Supported Resolutions (Video input): 1080p, 1080i, 720p, 576p, 480p, 480i
Record Format: MPEG 4 (H.264+AAC) / MJPEG
Dimension (W x D x H):125 x 151 x 21.5 mm (4.92 x 5.94 x 0.84 in)
Weight:145 g (5.11 oz.)
Notes:
LGHD2 does not support viewing/recording/streaming of HDCP protected signals
Interface: PCI Express x1 Gen 2
Ports In: HDMI*, 3.5mm audio
* LGHD2 does not support viewing/recording/streaming of HDCP protected signals
