Primary Ports: 48 x 10/100/1000Base-T 802.3at (30W) ports
• Full/Half-Duplex (autosensing)
• MACsec-capable
8 x 1Gb SFP uplink ports (includes 2 x Stacking ports @ 10Gb)
• Can be upgraded to 10Gb SFP+ via software license
• MACsec-capable
• 100Mb operation supported on last 4 uplink ports
1 x Serial console port (RJ-45)
1 x USB A ports for management or external USB flash
1 x USB Micro-B console port
PoE: All 5320 models support 30W PoE that conforms with IEEE 802.3at. This enables the 5320 to address the needs of powered edge devices, while eliminating the need for additional electrical cabling and circuits. In addition, 5320 PoE models support perpetual and fast PoE for even more efficient and reliable powered edge device operation.
Features: • 1 x Gigabit PoE+ input port
• 2 x Gigabit PoE output ports
• 2 x Gigabit ports
• 18W PoE power budget
• Easy to use web-based management interface
• Supports static link aggregation, VLAN, QoS, STP, RSTP and IGMP Snooping
• Voice VLAN for VoIP applications
• Bandwidth control per port
• 10Gbps switching capacity
• 802.1p / DSCP / Queue Scheduling (SP/WRR) QoS support
• Compact fanless
