Specifications: Interfaces
Serial
4 x Programmable Bi-directional RS-232/422/485 Port
(4 x DB9 Male Connector, configurable via pin assignments);
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd;
Flow Control: None (default) RTS/CTS
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A
Power: Consumption 5 VDC, 7.5 W(adapter) ; 48VDC, 9.5 W(PoE, PoE 802.3 AF/AT compatibility)
Specification: Ports In:
1 x HDMI Female
Ports Out:
Video Output: 1 x HDMI Female
Audio Output: 1 x TOSLINK (Optical) / 1 x RCA (Coaxial) / 2 x RCA (Stereo)
1 x DC Jack
Console Connectors (Flash ROM Upgrade): 1 x 4-conductor 3.5 mm Jack
1 x (Green) Power On LED
Switches
Mode Selection: Audio Channel - 1 x Slide Switch / HDMI Audio On/Off - 1 x Slide Switch
F/W Upgrade: 1 x semi-recessed pushbutton
Power: 5.3 VDc/150 mA
Power Consumption: 0.8 W - 3 BTU / hr
Dimension: 7.9" x 3.2" x 1"
Weight: 1 lbs.
Feature: Repeats HDMI input signal up to 15 meters
Extracts HDMI audio signal and outputs as additional audio source
Supports optical / coaxial digital audio and analog stereo audio
HDMI and HDCP compatible
Super Video Quality - up to 1920x1080 (1080p)
Firmware upgradable
CH2/CH5...
Specifications: VE803T
Connectors
HDMI In: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type B Female (White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches:
EDID Selection: 1 x slide switch
LEDs
Power: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 1W
PhysicalProperties
Housing: Metal
VE803R
Connectors
HDMI Out: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type A Female(White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches
EQ Compensation: 1 x 8 position switch
LEDs
Power: 1 (Green)
HDMI: 1 (Green)
USB: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 3.9W
PhysicalProperties
Housing: Metal
Specifications: Audio: Supports high-definition audio (HD) 5.1/6.1/7.1 surround sound: Dolby TrueHD, DTS-HD Master Audio LPCM channels up to 7.1 channels 192 kHz
Operating Humidity: 0 to 80% relative humidity
Operating Temperature: 32° to 122° F (0° to 50° C)
PoE: Complies with IEEE 802.3at standard, Class 4;
Power: Normal input: 48 VDC;
Input Range: 36 to 57 VDC
Power: (1) External 5 VDC, 3 A
Power Consumption: POE: 10.5 W
Storage Temperature: -4° to +140° F (-20° to +60° C)
User Controls:
B1: Set/Reset Pushbutton;
B2: Function Selection Pushbutton;
Rotary switch: Select from 16 Video Channels (HEX 0–F), Paired TX and RX units must use the same channel
Specifications: Connectors
Video In: 1 x HDB-15 Male (Blue)
Video Out: 1 x HDB-15 Female (Blue)
Audio In: 1 x Audio Jack Female (Green)
Audio Out: 1 x Audio Jack Female (Green)
Unit to Unit: 1 x RJ-45 Female
Power: 1 x DC Jack
LEDs
Power: 1 (Green)VE170R, VE170RQ
Switch
Manual Gain Control: 2 x Knob (VE170R, VE170RQ)
RGB Tuner: 3 x Knob (VE170RQ)
Cable Distance: 1000 feet (300 m)
Power Consumption
VE170T: DC 5.3V, 0.9W
VE170R: DC 5.3V, 1.11W
VE170RQ: DC5.3V, 4.82W
Video
VE170T, VE170R:
1920 x 1200 at 60Hz, 100 feet(30 m)
1600 x 1200 at 60Hz, 500 feet(150 m)
1024 x 768 at 60Hz, 1000 feet(300 m)
VE170RQ:
1920 x 1200 at 60Hz, 500 feet(150 m)
1280 x 1024 at 60Hz, 1000 feet(300 m)
Specifications: Interfaces
Relay
8 normally open relays (8 x 2-pole terminal block)
Contact Rating: Max 24 VDC, 2A
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A (Firmware upgrade only)
Power
Consumption 5 VDC, 10 W (Adapter); 48 VDC, 13 W (PoE, PoE 802.3 AF/AT compatibility)
Output 12 VDC, 300 mA
Specifications: Interfaces
IR/Serial 6 x Programmable IR / Uni-directional RS-232 Port
6 x 2-Pole Terminal Block Connector
IR: TTL level (0 to 5 V)
Carrier Frequency: 10 - 455 KHz;
Serial: Uni-directional RS-232 ( + - 5 V)
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A (Firmware upgrade only)
Power: Consumption 5VDC, 8W(adapter); 48V, 10.5W (PoE, PoE 802.3 AF/AT compatibility)...
Package Contents: VIVE Pro Headset
Headset cable
Base Station 2.0 (x2)
Power adapter (x2)
Controller (2018) (x2)
Power adapter (x2)
Micro-USB cable (x2)
Link Box for VIVE Pro
Power adapter
DisplayPort cable
USB 3.0 cable
Feature: ENHANCED GRAPHICS - Super-rich colors and sharper than ever details: 2880 x 1660 and 615 PPI
REAL-LIFE MOVEMENT - 360-degree controller and headset tracking covers your movements to the millimeter, floor-to-ceiling
IMMERSIVE AUDIO - Feel sound all around you with hi-res, high impedance headphones with active noise cancellation
DEFINE YOUR PLAYSPACE - Use VIVE seated, standing, or in a space up to 20.0 x 20.0 Feet, with supporting base stations
DESIGNED FOR COMFORT - Enhanced ergonomics of the headset allows for greater comfort in VR for longer game play
Wireless Data Rates: 802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 450 Mbps
WiFi 4 (802.11n) (1024QAM) : up to 750 Mbps
WiFi 5 (802.11ac) (1024QAM) : up to 4333 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 861 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps
Frequency Band: 2.4 GHz / 5 GHz
WAN Ports: RJ45 for 10/100/1000 BaseT for WAN x 1
RJ45 for 10/100/1000 BaseT for LAN x 4
Five (5) 10/100/1000 Mbps Gigabit Ethernet ports + one (1) 2.5G/1Gbps multi-Gig port (configurable)
-- LAN: 4xGbE (2x port aggregation LAN)
-- WAN: 1 GbE
-- WAN/LAN: 2.5G/1Gbps multi-Gig port (configurable)
-- Multi-Gig: Ability to aggregate two Gigabit LAN ports and two Gigabit WAN ports (configurable) concurrently.
USB 3.2 Gen1 x1, 2.0 x1
