Specification: Hardware
Audio: No
Industry Standards: DDC compatible - all other monitors must be able to support the highest video resolution of the DDC-type monitor connected to Video Out 1
Ports: 2
Regulatory Approvals: FCC Part 15 Class A, CE Mark
Performance
General Specifications: Male to Female VGA extension cable required (MXT101HQ)
Maximum Cable Length: 213.2 ft. [65m]
MTBF: 1,588,136 Hours
Environmental
Humidity: 0~80% RH Non-condensing
Operating Temperature: 5 degree C to 40 degree C (41 degree F to 104 degree F)
Resolution Support: Maximum Analog Resolutions: 2048x1536 @ 80Hz
Specification: Color: Black
Maximum Resolution: 1080p @ 60Hz
HDMI Version: HDMI 1.2
Power: 5V DC
HDCP: Yes, HDCP 1.1
DVI Version: DVI 1.0
Ports In:
1 x 3.5mm analog audio (two channel)
1 x Digital Coax Audio
3 x Component RCA (YPbPr/YCbCr)
Ports out:
1 x HDMI Connector
Feature: Compliant with HDMI 1.2/HDCP 1.1/DVI 1.0
Supports a maximum resolution of 1080p
Supports digital and analog audio input
Supports stand and high definition video output
Distance: Maximum Distances - (1080i only)
CAT5E (stranded) - 40m (130 ft.)
CAT5E (solid) - 50m (165 ft.)
CAT6 (stranded or solid) - 50m (165 ft.)
Max Distance: 50m / 165 ft.
Resolution Support: Maximum Digital Resolutions: 1080p / 1920x1080
Supported Resolutions:
1080i
- Cat6 (stranded or solid) - up to 50m
- Cat5e (solid) - up to 50m
- Cat5e (stranded) - up to 40m
1080p
- Cat6 (solid or stranded) - up to 40m
- Cat5 (solid) - up to 20m
- Cat5 (stranded) - up to 16m
See product manual for further details
HDMI: Local Unit Connectors:
1 x HDMI (19-pin) Female
Remote Unit Connectors:
1 x HDMI (19-pin) Female
Network Interface: Local Unit Connectors:
2 x RJ-45 Female
Remote Unit Connectors:
2 x RJ-45 Female
System Requirements: Computer with an HD15 port
VGA or SVGA monitor with HD15M cable
Specification: Rugged Metal Case
Feature: Connects two computers to one monitor or two monitors to one computer
Fully-shielded rugged metal case with front-panel push button switch
Does not require external power, software, or complicated set-up procedures
Distance: Max 1024 x 768 Range (ft.): 100
Max 480P Range (ft.): 100
Max 1440 x 900 Range (ft.): 100
Max 1080i Range (ft.): 100
Max 1080P Range (ft.): 50
Max 480i Range (ft.): 100
Max 640 x 480 Range (ft.): 100
Max 800 x 600 Range (ft.): 100
Max 1600 x 1200 Range (ft.): 100
Max 720P Range (ft.): 100
Power Supply: Input: 100-240V, 50/60Hz, 0.5A
Output: 5V, 2A
Specification: Connector A:3 x HD15 (FEMALE)
Connector B:2 x RJ45 (FEMALE)
Maximum Operating Distance:1000 ft
Number of Output Devices Supported:2
Number of Input Devices Supported:1
Twisted Pair Cable Standard:Category 6
Media Type Supported:Twisted Pair
Resolution Support: Maximum Digital Resolutions: 3840 x 2160 (4K) @ 60 Hz
Supported Resolutions:
3840 x 2160 (4K) 60 Hz
2560 x 1600 60 Hz
1920 x 1200 60 Hz
1920 x 1080 (1080p) 60 Hz
1280 x 720 (720p) 60 Hz
* Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Audio: 7.1 Surround Sound
HDMI: Connector A: 1 x HDMI (19-pin) Female
Connector B: 1 x HDMI (19-pin) Female
Specification: Hardware
Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: No
Output Signal: HDMI
Ports: 1
Rack-Mountable: Yes
Performance
Audio Specifications: 7.1 Surround Sound
Max Distance: 70 m / 230 ft
Maximum Cable Length: 0.2 ft [0.1 m]
Maximum Digital Resolutions: 4096 x 2160 (4K) @ 30 Hz
Wide Screen Supported: Yes
Connector(s)
Connector A:
- 1 x HDMI (19 pin) Female Input
- 1 x
Feature: Extend HDMI video over CAT5 or CAT6 cabling up to 230 feet away, with a small USB-powered transmitter for discreet installation
Works with HDMI video sources such as Blu-ray players & computers and HDMI televisions monitors and projectors
HDBaseT Extender / HDMI over single CAT 5 or CAT 6 Ethernet Extender /
Resolution Support: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a);
1080p@100m
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60 Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30 Hz (4:4:4)
Video: Video
Max. Data Rate: 10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock: Up to 340 MHz
Compliance:
HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
Distance: Max Distance: 70m (230 ft.)
Maximum 1080p Distance: 70m (230 ft.)
Maximum 4K Distance: 35m (115 ft.)
Resolution Support: 4K x 2K (Ultra HD) @ 30 Hz
2560 x 1600 @ 60 Hz
1920 x 1200
1920 x 1080 (1080p)
1280 x 720 (720p)
Power Consumption: 64.8W
Power Supply: Center Tip Polarity: Positive
Input Current: 1.5A
Input Voltage: 100 ~ 240 AC
Output Current: 2.7A
Output Voltage: 24 DC
Plug Type: 4-pin DIN
Power Source: AC Adapter Included
Power Supply: Dual Power Supply (Y/N): Yes
Power Source Type: AC Adapter
Feature: AC Power Adapter Plug(s): NEMA 5-15P North America
AC Power Adapter Input Specs (V / Hz / A): 90-240V / 50/60Hz / 2A
AC Power Adapter Output Specs (V / A): 12V / 6.5A
AC Power Adapter Cord Length (ft.): 6
AC Power Adapter Cord Length (m): 1.83
Front Panel LEDs: FAN 1-3 (x3); SLOT 1-12 (x12)
Product Compliance: Trade Agreements Act (TAA)
Dimensions: Unit Dimensions (hwd / in.): 11.420 x 16.930 x 5.240
Package Content: Package Includes:
N785-CH12 3U 12-Slot Media Converter Chassis
N785-CH75W-AC Power supply with 6 ft. power cord, NEMA 5-15P plug and glass-tube fuse (Input: 90–240V, 50/60 Hz, 2A; Output: 12V 6.5A)
(2) Mounting brackets
(24) Mounting panels
(2) Rack-mount kits
(48) M3 6x5 mm screws
(10) F3 6x5 mm screws
(6) M5 16x10 mm screws
(4) ...
